LG 55VL5PJ-A – 55-inch 3.5mm Bezel Video Wall

Product Overview

The LG 55VL5PJ-A is a 55-inch narrow bezel video wall display for retail, corporate and hospitality installations that need large-format imaging at an accessible price tier. A 3.5mm bezel-to-bezel seam and IPS panel let multiple units combine into a clean tiled surface, while a built-in SoC and webOS smart signage platform run content without an external media player. Rated for 24/7 operation in portrait or landscape, it suits always-on commercial video wall deployments. Built-in Tile Matrix software supports configurations up to 15 x 15 displays without an external processor.

Product Description

The VL5PJ-A works as a stand-alone 55-inch display or as a building block for a tiled video wall display with a narrow 3.5mm bezel-to-bezel seam. Daisy-chain connectivity over HDMI, DisplayPort and DVI-D, with a DisplayPort loop-through output, lets a single source feed a chain of panels while passing control, monitoring and firmware updates downstream. Built-in Tile Matrix software configures arrays up to 15 x 15 without external scaling hardware, and an image-gap-reduction algorithm keeps motion continuous across bezel boundaries. The 500-nit IPS panel maintains wide-angle color, and a 3% haze surface limits reflection in lit rooms. The embedded webOS platform and content scheduling tools run on-board, and optional LG ConnectedCare adds cloud-based remote fault diagnosis and management. For a brighter, tighter-bezel video wall in demanding rooms, the LG 55VSH7J-H 0.44mm bezel video wall is a step-up option.

Key Features

• 3.5mm Bezel-to-Bezel Seam — A narrow combined bezel keeps the tiled image clean for multi-panel video walls.
• 500-Nit IPS Panel — IPS technology holds color and contrast across wide viewing angles for large surfaces.
• 24/7 Duty Cycle — Rated for continuous operation in portrait or landscape for always-on commercial signage.
• Built-in Tile Matrix (up to 15 x 15) — On-board tiling configures large arrays without an external video processor.
• Daisy-Chain Connectivity — HDMI, DisplayPort and DVI-D inputs with DisplayPort output pass video, control and firmware updates down the chain.
• Image Gap Reduction — Processing adjusts objects crossing bezels so motion appears continuous across tiles.
• webOS Smart Signage Platform — Built-in SoC runs content and apps without a separate media player, with HTML5/SDK support.
• LG ConnectedCare Ready — Optional cloud service adds remote fault diagnosis and fleet management (additional license required).
• Integration-Friendly Control — Crestron Connected 2, HDMI CEC, RS-232 sync, SNMP and data cloning support standard AV control workflows.

Typical Applications

• Conference room — Tiled walls for collaborative content and data display.
• Commercial meeting space — Retail, corporate and hospitality lobby video walls for branding and information.
• Multi-purpose room — Flexible large-format display for varied event and presentation needs.
• Government space — Always-on public-information and operations walls.
• All-hands room — Large viewing surface for company-wide meetings.

Technical Specifications

Competitor Comparison

Frequently Asked Questions

Can the 55VL5PJ-A run as a single display as well as in a wall?
Yes. It operates as a stand-alone 55-inch display or combines into a tiled video wall with a 3.5mm bezel-to-bezel seam, with built-in Tile Matrix handling array configuration.

How does daisy-chaining work for installation?
HDMI, DisplayPort and DVI-D inputs plus a DisplayPort loop-through output let one source feed a chain of panels while passing control, monitoring and firmware updates downstream, reducing cabling and external hardware.

Does it integrate with Crestron or other control systems?
It supports Crestron Connected 2, HDMI CEC, RS-232 sync and SNMP, and the optional LG ConnectedCare cloud service adds remote fault diagnosis and fleet management.

Is it suitable for continuous operation?
The panel is rated for 24/7 duty cycle in portrait or landscape, with IP5X dust protection, suiting always-on retail, corporate and hospitality deployments.

What warranty and support apply?
The display carries LG's commercial video wall warranty. Creation Networks can advise on coverage, mounting systems and ConnectedCare licensing during specification.
