JBL Control 418C/T – 8" Two-Way Coaxial Ceiling Loudspeaker

Product Overview

The JBL Control 418C/T is an 8-inch two-way coaxial ceiling loudspeaker from JBL's Control 400 Standard Coverage Series, built for clear, even sound in commercial AV installations. It combines an 8-inch woofer with a coaxially mounted 1-inch soft-dome tweeter and a built-in 70V/100V multi-tap transformer, so this commercial ceiling loudspeaker works in both distributed-audio and low-impedance systems. A 100° coverage pattern delivers consistent on- and off-axis performance, and a pre-attached plenum-rated enclosure with a bezel-less paintable grille supports fast, clean integration into modern interiors.

Product Description

The Control 418C/T is engineered for commercial spaces that need stronger output and wide, consistent coverage than a basic background-music driver provides. Its 8-inch treated-paper woofer with a copper-clad aluminum voice coil pairs with a coaxial 1-inch neodymium soft-dome tweeter for a wide 57 Hz–20 kHz frequency range and pleasant, enveloping sound throughout the listening area. As a 70V/100V ceiling speaker, it includes a 60 W multi-tap transformer for distributed lines plus an 8-ohm direct setting for low-impedance, direct-drive configurations, and handles 135 W continuous pink noise (540 W peak). The integrated enclosure is suitable for most plenum spaces and is listed for air-handling use per UL 2043, NFPA 90A and NFPA 70, and CSA C22.2 no. 205, with UL 1480A listing and a UL-registered transformer. Installation-focused features include a pre-attached backcan, C-ring backing, tile rails, cutout template, cable strain relief, a captive dogear design for varied ceiling thicknesses, a terminal cover for top or side cable entry, and an integrated safety tether. The full-face magnetic grille is bezel-less and paintable, with optional round (black) and square (white) grilles available. For a higher-output 8-inch coaxial ceiling option, the JBL Control 328CT offers 250 W handling on the same distributed-audio principle.

Key Features

• 8-inch coaxial design — An 8-inch woofer and coaxial 1-inch soft-dome tweeter deliver time-aligned, full-range output across the room.
• Built-in 70V/100V transformer — A 60 W multi-tap transformer plus 8-ohm direct setting supports distributed and low-impedance systems.
• 100° standard coverage — A wide, even pattern maintains consistent performance for on- and off-axis listeners.
• 135 W power handling — 540 W peak handling provides headroom for music and paging in commercial spaces.
• Plenum-rated enclosure — Listed for air-handling spaces per UL 2043, NFPA 90A/70, and CSA, with UL 1480A listing.
• Fast, repeatable install — Pre-attached backcan, C-ring, tile rails, cutout template, captive dogears, and safety tether speed deployment.
• Bezel-less paintable grille — A full-face magnetic grille blends into any décor and can be painted; optional round/square grilles available.

Typical Applications

• Conference room — Clear program and voice reproduction in standard ceiling-grid layouts.
• Commercial meeting space — Even distributed coverage across lobbies, atriums, and gathering areas.
• Multi-purpose room — Wide, consistent coverage with headroom for varied program material.
• Training room — Intelligible speech across wide seating areas.
• House of worship — Distributed ceiling coverage for speech and music.
• Government space — Reliable paging and announcement coverage in civic interiors.

Technical Specifications

What's in the Box

• JBL Control 418C/T 8" coaxial ceiling loudspeaker with pre-attached backcan
• C-ring backing plate, tile rails, and cutout template
• Cable strain relief and terminal cover
• Installation/spec documentation

Note: Optional JBL-MTC-418BG round (black) and JBL-MTC-418SG square (white) grilles, and MTC-447NC/MTC-447MR construction brackets, are sold separately.

Frequently Asked Questions

Can the Control 418C/T run on 70V/100V and 8-ohm systems?
Yes. It includes a 60 W multi-tap 70V/100V transformer for distributed lines and an 8-ohm direct setting for low-impedance, direct-drive installations.

Is it suitable for plenum (air-handling) ceilings?
Yes. The integrated enclosure is listed for air-handling spaces per UL 2043, NFPA 90A and NFPA 70, and CSA C22.2 no. 205, with UL 1480A listing.

What installation hardware is included?
A pre-attached backcan, C-ring backing, tile rails, cutout template, cable strain relief, captive dogears, terminal cover, and integrated safety tether are included for fast, repeatable installation.

Can the grille be painted to match the ceiling?
Yes. The bezel-less full-face magnetic grille is paintable, and optional black round and white square grilles are available for additional customization.

What warranty and support apply?
The Control 418C/T carries JBL Professional's manufacturer warranty. For coverage planning, tap selection, and integration support, contact our team at sales@creationnetworks.net or browse the full JBL Professional collection.
