Eaton PDU3EVNR6G60A – 16.2kW 3-Phase Monitored PDU
Product Overview
The Eaton PDU3EVNR6G60A is a 16.2kW 3-phase monitored PDU built for high-capacity data center racks running on 208/240V 3-phase power. This 0U vertical unit uses an IEC309 60A blue input plug and provides per-outlet monitoring across 18 total outlets, making it a strong fit for enterprise server rooms that need granular load visibility. Its Eaton LX platform interface adds a Gigabit network connection and LCD display for remote and on-site monitoring. IT and facilities teams specifying a monitored 3-phase PDU with high amperage input will find this model suited to demanding compute racks.
Product Description
This PDU runs on a 3-phase, 208/240V circuit rated for a 60A IEC309 blue locking input plug, a common connector for high-amperage data center circuits. It distributes power across 6x C13 and 12x C19 outlets (18 total), giving flexibility for a mix of servers, switches, and higher-draw equipment that typically uses C19-style connectors. Unlike basic input-only metered PDUs, this model provides monitored, per-outlet-level data through the Eaton LX platform, which includes a Gigabit network module and built-in LCD for checking load without a separate monitoring tool. The 0U vertical form factor mounts along the rear rail of the rack, preserving usable rack unit space for compute and networking gear. This PDU is well suited to enterprise data centers, colocation cabinets, and high-density server rooms that need per-outlet monitoring on a high-amperage 3-phase circuit.
Key Features
- 16.2kW 3-Phase Capacity — Supports high-density racks on a 208/240V 3-phase circuit.
- 18 Total Outlets (6x C13, 12x C19) — Configured with a higher proportion of C19 outlets for larger equipment.
- IEC309 60A Blue Input Plug — Matches high-amperage 3-phase circuits common in data centers.
- Per-Outlet Monitoring — Tracks load at the individual outlet level for granular visibility.
- Gigabit Network Module with LCD — Enables remote monitoring alongside on-site display readouts.
- 0U Vertical Mounting — Frees up horizontal rack space for equipment.
Technical Specifications
| Spec | Value |
|---|---|
| Power Rating | 16.2 kW |
| Input Voltage | 208/240V, 3-phase |
| Input Plug | IEC309 60A, Blue |
| Output Receptacles | 6x C13, 12x C19 (18 total) |
| Form Factor | 0U, vertical |
| Monitoring | Monitored, per-outlet, Eaton LX platform with Gigabit network module and LCD |
