Eaton PDU3EVN6L1530B – 10kW 3-Phase Metered Rack PDU

Product Overview

The Eaton PDU3EVN6L1530B is a 10kW 3-phase metered rack PDU built for data center and server room power distribution where real-time load visibility matters. This 0U vertical PDU gives IT and facilities teams a reliable way to monitor amperage draw and prevent circuit overloads across dense server racks. With 48 total outlets and an integrated LCD display, it suits commercial AV and IT deployments that need a metered PDU with a large outlet count in a single vertical unit. Integrators specifying 3-phase metered PDUs with an L15-30P input for enterprise racks will find this model a straightforward fit.

Product Description

This PDU mounts vertically (0U) along the rear rail of a standard server rack, preserving horizontal rack unit space for compute and networking gear. It accepts a 3-phase, 200-208-240V feed through an L15-30P input plug and distributes power to 42x C13 and 6x C19 outlets, giving equipment installers flexibility for servers, switches, and other IEC-corded devices. The unit includes a built-in touchscreen LCD that displays real-time input current and voltage so on-site technicians can spot-check load without a laptop or network connection. A 6 ft. input cord is included, typical for 0U vertical PDUs feeding from an overhead or side-mounted circuit. Because this is a metered (not switched or outlet-managed) PDU, it reports load data at the PDU/input level rather than switching or monitoring at the individual outlet — a cost-effective option for racks where load visibility is the priority but remote outlet control is not required. This model is commonly deployed in colocation cabinets, network closets, and mixed AV/IT equipment racks where a dense C13/C19 outlet count is needed on a single 3-phase circuit.

Key Features

• 10kW 3-Phase Capacity — Supports high-density racks running 200-208-240V 3-phase power without needing multiple single-phase PDUs.
• 48 Total Outlets (42x C13, 6x C19) — Accommodates a large mix of standard IEC power cords across servers, switches, and storage.
• Integrated LCD Display — Shows real-time voltage and current readings directly on the unit for fast on-site checks.
• 0U Vertical Mounting — Installs in the rear of the rack without consuming rack unit space needed for equipment.
• L15-30P Input Plug — Matches standard 3-phase 30A receptacles common in data center and server room circuits.
• Metered Input Monitoring — Provides load-level visibility to help prevent circuit overloads and support capacity planning.

Technical Specifications
