Crown DCI2X600 DriveCore Install Analog 2 Channel 2x600 Watt Amplifier
Crown DCI2X600 DriveCore Install Analog 2 Channel 2x600 Watt Amplifier is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Crown DCI2X600 DriveCore Install Analog 2 Channel 2x600 Watt Amplifier
Crown DCI2X600 – 2-Channel 600W DriveCore Install Analog Amplifier
Product Overview
The Crown DCI2X600 is a two-channel, 600-watt-per-channel installation amplifier built for commercial AV systems requiring higher output power in a compact 1U rack chassis. Part of Crown's DriveCore Install Analog Series, the DCI2X600 is specified by AV integrators for main speaker systems in conference rooms, multi-purpose rooms, houses of worship, and commercial facilities where 70V distributed audio or direct-drive low-impedance speaker loads demand consistent high-output performance.
Product Description
The DCI2X600 delivers 600 watts per channel into 4 ohms across both channels with full 70V and 100V constant-voltage support in a 1U rack-mount chassis. Crown's DriveCore IC integrates the driver and output stages, improving thermal efficiency and long-term reliability in permanent commercial rack installations. Onboard DSP provides per-channel limiting, parametric EQ, crossover filtering, and alignment delay. HiQnet protocol support enables remote monitoring and control from Harman system management platforms. The amplifier includes comprehensive DC, thermal, and short-circuit protection for connected speaker systems.
Key Features
- 600W per channel at 4Ω — High output for main speaker systems in conference rooms, multi-purpose rooms, and commercial spaces.
- 70V/100V constant-voltage output — Both channels support distributed speaker systems with extended cable runs.
- Crown DriveCore technology — Integrated IC reduces thermal load in enclosed rack installations.
- Onboard DSP — Per-channel limiting, EQ, crossover, and delay without external processing.
- HiQnet network control — Remote monitoring and integration with Harman AV platforms.
- 1U rack-mount chassis — Compact form factor for commercial AV equipment racks.
- Independent channel configuration — Each channel independently configurable for zone-specific settings.
- Comprehensive protection — DC, thermal, and short-circuit protection on both channels.
- Balanced XLR inputs — Professional input connectivity for commercial AV signal paths.
- PureBand Flatness — Consistent frequency response across the full audio bandwidth.
Typical Applications
- Conference room and boardroom main speaker systems
- Multi-purpose room and all-hands room audio
- House of worship main and fill speaker amplification
- Commercial meeting space foreground audio
- Government facility public address amplification
- Training room and auditorium fill speaker systems
- Distributed 70V speaker systems in commercial facilities
Technical Specifications
| Specification | Value |
|---|---|
| Channels | 2 |
| Power Output (4Ω) | 600W per channel |
| Power Output (8Ω) | 300W per channel |
| 70V/100V Support | Yes |
| DSP | Built-in per channel |
| Network Control | HiQnet |
| THD+N | <0.35% |
| Frequency Response | 20Hz–20kHz ±0.5dB |
| Rack Spaces | 1U |
| SKU | DCI2X600-U-USFX |
Competitor Comparison
| Criteria | Crown DCI2X600 | QSC CX-Q 2K4 | Lab.gruppen C 2-4X | Biamp Amp 2 |
|---|---|---|---|---|
| Channels | 2 | 2 | 2 | 2 |
| Power per ch (4Ω) | 600W | 500W | 400W | 250W |
| 70V/100V | Yes | Yes | Yes | Yes |
| Onboard DSP | Full per channel | Via Q-SYS Core | Limited | Biamp native |
| Network Control | HiQnet | Q-SYS | Lake optional | Biamp TesiraFORTÉ |
| Form Factor | 1U | 1U | 1U | 1U |
Frequently Asked Questions
- Can the DCI2X600 be bridged for higher mono output?
- Yes. Both channels can be bridged for higher mono output. Refer to the Crown installation guide for bridged-mode minimum impedance requirements.
- Is the DCI2X600 suitable for 70V distributed ceiling speaker systems?
- Yes. Both channels support 70V and 100V constant-voltage output for commercial distributed speaker installations.
- Does the DCI2X600 require an external DSP processor?
- Not for standard installations. Onboard DSP handles per-channel limiting, EQ, crossover, and delay.
- What is the warranty?
- Crown professional installation amplifiers carry a 3-year limited warranty. Contact Creation Networks for service information.
