Crestron HZ2-SWEX-A – In-Wall Wireless Switch, Almond

Product Overview

The Crestron HZ2-SWEX-A is a single-gang in-wall on/off switch that communicates wirelessly over the infiNET EX 2.4 GHz mesh network. Designed for 120 VAC loads, it operates without a wired control run from each device back to a processor, reducing installation labor in retrofit and new-construction commercial projects. The Almond finish aligns with standard Leviton and Lutron almond trim plates, making it a practical choice for spaces where mixed-brand control hardware must present a consistent appearance.

Product Description

The HZ2-SWEX-A belongs to the Crestron Horizon 2 series — a line of in-wall lighting control devices built around infiNET EX wireless mesh technology. The switch handles non-dimming 120 VAC loads and ships with standard factory engraving. It mounts in a single-gang decora opening and requires an infiNET EX gateway (such as the CEN-GWEXER) on the network to communicate with a Crestron control system.

For commercial environments where running additional low-voltage wiring is cost-prohibitive or structurally impractical, infiNET EX mesh provides a reliable wireless path with self-healing routing and AES-128 encryption. The Almond colorway ($410) covers applications in hospitality, healthcare, and education facilities where almond trim is an established standard.

Key Features

• Non-dimming on/off control for 120 VAC loads
• infiNET EX 2.4 GHz wireless mesh communication
• AES-128 encrypted wireless link
• Single-gang decora form factor
• Almond finish compatible with standard almond trim plates
• Standard factory engraving included
• Requires infiNET EX gateway for system integration
• Part of the Crestron Horizon 2 lighting control ecosystem

Typical Applications

• Conference rooms and boardrooms with existing decora almond trim
• Hospitality guest rooms and corridors requiring wireless retrofit
• Healthcare facilities with almond finish standards
• Education classrooms where running new wiring is not feasible
• Multi-tenant office spaces with mixed lighting control brands

Technical Specifications

• SKU: HZ2-SWEX-A
• Load Type: Non-dimming on/off, 120 VAC
• Wireless Protocol: infiNET EX 2.4 GHz mesh
• Encryption: AES-128
• Form Factor: Single-gang decora
• Finish: Almond
• Engraving: Standard (factory)
• Gateway Required: Yes (infiNET EX gateway, sold separately)
• Voltage: 120 VAC

Frequently Asked Questions

Does the HZ2-SWEX-A require a neutral wire?

Crestron's wiring requirements for the Horizon 2 series depend on the specific installation. Consult the HZ2-SWEX-A installation guide or contact Crestron technical support to confirm wiring needs for your load type and panel configuration.

What gateway is required for this switch?

The HZ2-SWEX-A requires an infiNET EX gateway on the Crestron network. The CEN-GWEXER is the standard gateway used in most deployments. The gateway count needed depends on the size of the installation and the number of infiNET EX devices in the mesh.

Can this switch be used as a standalone device without a Crestron processor?

No. The HZ2-SWEX-A is designed to operate within a Crestron control system via an infiNET EX gateway. It is not a standalone smart switch and requires system programming to function.
