AVPro Edge MXNET Evolution II 4k@60 4:4:4 IP Multiviewer The Evolution II IP Multiviewer displays up to four 4K60 AV over IP streams in customizable layouts with flexible scaling.

Product Overview

The AVPro Edge AC-MXNET-1G-MV41V2 is a dedicated IP multiviewer for MXNet Evolution II AV-over-IP systems, capable of displaying up to four simultaneous 4K@60Hz 4:4:4 streams on a single output display. Designed for control rooms, network operations centers, and large-venue monitoring applications, it gives operators a consolidated view of multiple AV-over-IP sources without requiring separate decoders for each signal. Full integration with the MXNet EV2 ecosystem means layout configuration, source selection, and scaling are managed through the same controller used for the broader AV distribution system. At $6,699, it provides a cost-effective alternative to deploying four independent decoders for multi-source monitoring.

Product Description

The AC-MXNET-1G-MV41V2 connects directly to the MXNet Evolution II network and pulls up to four independent AV-over-IP streams simultaneously, compositing them into a single output at up to 4K@60Hz with full 4:4:4 chroma subsampling. This means no color compression artifacts — critical for applications like broadcast confidence monitoring, medical imaging review, or any scenario where color accuracy matters.

Layouts are fully configurable — operators can arrange source windows in any position and size within the output frame, with independent scaling applied per input. Common configurations include equal-quadrant views, picture-in-picture, and custom asymmetric arrangements suited to specific monitoring workflows. All layout changes are applied in real time without signal interruption.

Control is entirely network-based through the MXNet controller, making this unit a natural fit for installations already running the MXNet EV2 ecosystem. The unit is rack-mountable and designed for continuous 24/7 operation in professional AV environments. Its ultra-low latency processing ensures that monitoring displays remain synchronized with live sources — important for broadcast tally and real-time confidence monitoring.

Key Features

• Up to Four Simultaneous 4K@60 Streams — Displays four independent AV-over-IP sources on a single output without requiring separate decoder hardware for each signal.
• Full 4:4:4 Chroma Subsampling — Maintains complete color information on all inputs and the output, preserving accuracy for broadcast, medical, and precision monitoring applications.
• Fully Customizable Layouts — Operators configure source window positions, sizes, and arrangements freely within the output frame to match specific workflow requirements.
• Independent Per-Input Scaling — Each source window scales independently, allowing precise sizing without affecting other displayed sources.
• MXNet Evolution II Native Integration — Managed through the MXNet EV2 controller alongside encoders, decoders, and the broader AV distribution system — no separate multiviewer software required.
• Ultra-Low Latency Processing — Maintains near-real-time display of live sources, supporting confidence monitoring and broadcast tally applications.
• Network-Based Control — All configuration and source switching performed over the IP network through the MXNet controller interface.
• Rack-Mountable Form Factor — Fits standard 19-inch AV and IT equipment racks for professional installation.
• Continuous 24/7 Operation — Designed for always-on environments such as control rooms, NOCs, and broadcast facilities.

Typical Applications

• Broadcast master control rooms requiring confidence monitoring of multiple live feeds
• Network operations centers monitoring distributed AV-over-IP infrastructure
• Corporate AV control rooms consolidating feeds from multiple presentation spaces
• Sports venue production areas monitoring camera and replay sources simultaneously
• University AV departments monitoring distributed classroom and event feeds
• House of worship production booths consolidating multiple camera and presentation sources
• Digital signage management centers verifying content across multiple display zones

Technical Specifications

Competitor Comparison

Frequently Asked Questions

Does this multiviewer require a separate MXNet controller?

Yes. The AC-MXNET-1G-MV41V2 is managed through the MXNet Evolution II controller, which is the central management hub for the entire MXNet EV2 AV-over-IP system. If you are deploying a MXNet EV2 system, the controller is already part of your infrastructure.

Can I display fewer than four sources — for example, just two or three?

Yes. You can configure the multiviewer to display any number of sources from one to four. Unused windows can be hidden or the remaining sources can be scaled to fill more of the output frame.

What is the maximum output resolution?

The unit outputs up to 4K@60Hz (3840 x 2160) with full 4:4:4 chroma subsampling, providing a high-resolution composited view of all displayed sources.

Can layout configurations be saved and recalled?

Layout presets and source assignments are managed through the MXNet EV2 controller. Preset recall capability depends on the controller software version — consult AVPro Edge documentation for your specific controller firmware.

Is this unit compatible with non-MXNet AV-over-IP sources?

The AC-MXNET-1G-MV41V2 is designed for use within the MXNet Evolution II ecosystem. It pulls streams that are encoded and distributed by MXNet EV2 encoders. Non-MXNet AV-over-IP sources are not directly supported unless bridged through MXNet-compatible encoders.

Can the multiviewer output be connected to a standard display via HDMI?

The output connects to a display through standard HDMI. Verify display compatibility with 4K@60Hz 4:4:4 input for full quality output.
