Atlas Sound SH1-10 – Vented 1RU All-Purpose Rack Shelf

Product Overview

The Atlas Sound SH1-10 is a 1RU vented all-purpose rack shelf designed for 19-inch EIA-standard equipment racks. Constructed from 16-gauge cold-rolled steel with a flat black textured finish, the SH1-10 provides a sturdy platform for non-rack-mountable components such as media players, cable adapters, small wireless receivers, and miscellaneous AV accessories. Ventilation cutouts allow passive heat dissipation and accommodate optional 40mm tubeaxial cooling fans installed by the end user.

Product Description

The SH1-10 rack shelf occupies a single rack unit (1.75 inches) of rack space and extends 10 inches deep, providing sufficient platform area for most compact AV devices that lack rack-mount ears. The 16-gauge CRS construction provides a rigid, warp-resistant surface that holds up under the weight of typical rack accessories without flex or distortion. Mounting holes follow EIA standard spacing, ensuring compatibility with virtually all standard 19-inch two-post and four-post equipment racks. Multiple hole patterns across the shelf surface allow installers to secure non-rack gear using self-tapping fasteners or hook-and-loop mounting — a practical solution for equipment panels, media players, or cable pass-through hardware. The ventilation cutouts serve a dual purpose: they reduce material weight and allow convective airflow through the rack bay, which is especially useful when installed above or below heat-generating amplifiers or signal processors. No assembly is required; the SH1-10 ships ready to install. The flat black textured finish blends with standard rack equipment aesthetics and resists surface scuffs in contractor and facilities environments. Covered by Atlas Sound’s 60-month warranty.

Key Features

• 16-Gauge CRS Construction — Rigid steel platform handles everyday rack accessory loads without flex.
• Ventilation Cutouts — Passive heat dissipation; accommodates optional 40mm tubeaxial fans (by others).
• EIA Standard Mounting Holes — Compatible with all standard 19-inch two-post and four-post racks.
• Multiple Accessory Holes — Flexible mounting options for securing non-rack-mount gear.
• Flat Black Textured Finish — Matches standard rack aesthetics; scuff-resistant for contractor use.
• No Assembly Required — Ships ready to install, reducing labor time on rack builds.

Technical Specifications
