Atlas Sound ECM-20M – 20A AC Power Conditioner and Spike Suppressor

Product Overview

The Atlas Sound ECM-20M is a 20-amp AC power conditioner and spike suppressor designed for commercial AV rack installations where clean, protected AC power delivery is essential. Compatible as a standalone unit or as a module within the ECM-RACEWY6 raceway housing, the ECM-20M protects connected audio and video equipment from AC spikes, surges, and electromagnetic interference that can degrade performance or cause equipment damage. This commercial power conditioner supports integration with Atlas Sound ECS power sequencer controllers via remote activation at distances up to 1,000 feet, enabling centralized power management in distributed AV systems. The ETL-listed design meets UL 1449 standards for surge protective devices.

Product Description

The ECM-20M features both Radio Frequency Interference (RFI) and Electromagnetic Interference (EMI) noise filtering to remove unwanted signal contamination from sources such as electric motors, HVAC systems, and switching power supplies that commonly share electrical circuits with AV equipment. Clamping Suppression technology engages when AC spike or surge events occur, diverting excess voltage away from connected equipment before it can cause damage. The spike clamping circuit activates at a minimum of 460 VRMS at 3,000 amps, with a maximum clamping voltage of 6,000V, providing protection against both common power quality events and high-energy transients. AC mains voltage and current monitoring is included, along with Extreme Voltage Shutdown (EVS) circuitry that activates when line voltage falls below or exceeds the 102–132VAC operating window. Front-panel indicators include an Incoming AC Present LED and an Active LED for quick system status verification. The Manual/Auto On/Off switch provides local control independent of the remote activation interface. The ECM-20M provides two 20-amp outlets and is designed for housing in the Atlas Sound ECM-RACEWY6, which accepts multiple ECM modules for expanded outlet capacity directly connected to the AC mains. Power consumption of the unit itself is 0.5 watts, adding minimal load overhead. Dimensions of 3.0" H x 8.5" W x 3.5" D allow straightforward rack integration. The unit is ETL-certified to UL 1449 safety standards and carries a 60-month warranty.

Key Features

• 20A Rated Capacity with 2 Outlets — Handles full 20-amp circuit loads with two protected outlets per module.
• RFI and EMI Noise Filtering — Removes signal contamination from motors, HVAC, and switching power supplies on shared circuits.
• Clamping Spike & Surge Suppression — 460 VRMS minimum clamping voltage at 3,000A; 6,000V maximum spike protection.
• AC Mains Voltage & Current Monitoring — Real-time monitoring of line voltage and current draw for system health visibility.
• Extreme Voltage Shutdown (EVS) — Automatically disconnects outlets when line voltage falls outside 102–132VAC operating range.
• Remote Activation via ECS Controller — Compatible with Atlas Sound ECS power sequencers at distances up to 1,000 feet for centralized AV power management.
• Manual/Auto On/Off Switch — Local control independent of remote sequencer commands.
• ECM-RACEWY6 Compatible — Designed for modular housing in the ECM-RACEWY6 raceway for multi-outlet panel installations.
• ETL Listed to UL 1449 — Certified surge protective device meeting recognized safety standards.
• 60-Month Warranty — Five-year warranty coverage from date of purchase.
