| 12 V DC (10.8 V to 13.2 V) (Supplied AC adapter) |
IEEE802.3at compliant : DC42 to 57 V (Camera Input)
(Software authentication (LLDP) is supported) |
| 1.8 A (Supplied AC adaptor), 0.6 A (PoE+ power supply) |
| 0 °C to 40 °C (32 °F to 104 °F) |
| 20 ％ to 90 ％ (no condensation) |
| -20 °C to 50 °C (-4 °F to 122 °F) |
Approx. 1.8 kg (3.97 lbs) (excluding ceiling mounting bracket)
Approx. 2.05 kg (4.51 lbs) (including ceiling mounting bracket) |
| 160.0 mm x 192.1 mm x 166.0 mm (Excluding protrusions, cable cover, ceiling mounting bracket) |
| 6.299 inches x 7.563 inches x 6.535 inches (Excluding protrusions, cable cover, ceiling mounting bracket) |
| AW-RP150GJ, AW-RP60GJ, AW-RM50AG, AK-HRP1000*1,2, AK-HRP1005*1,2, AK-HRP1015*2, AK-HRP250*2 |
| 1/2.5-type 4K MOS x1 |
Motorized Optical 24x zoom, F1.8 to F4.0
[f=4.12 mm (5/32 inches) to 98.9 mm (3‑29/32 inches);
35 mm (1‑3/8 inches) equivalent: 25.0 mm (31/32 inches) to 600.0 mm (23‑5/8 inches)] |
- Optical zoom: 24x
- i.Zoom UHD 28x, FHD 36x
- Digital extender zoom: 1.4 x , 2 x
|
| Not supported |
Horizontal angle of view: 74.1° (wide) to 3.3° (tele)
Vertical angle of view: 46.0° (wide) to 1.9° (tele)
Diagonal angle of view: 81.8° (wide) to 3.8° (tele) |
| Switching between auto and manual |
Entire zooming range: 1200 mm (3.9 ft)
Wide end: 100 mm (0.33 ft) |
| 1MOS |
| 3 lx (F1.8, 59.94p, 50IRE, 42 dB, without accumulation) |
UHD: 1,500 Typ (Center area)
FHD: 1,000 Typ (Center area) |
| Auto, 0 dB to 36 dB*3 (Super Gain function equipped : 37 dB to 42 dB) |
| Auto, 0 dB, 6 dB, 12 dB, 18 dB, 24 dB*4 |
| 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000 |
| 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000 |
| 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000 |
| 1/25, 1/50, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000 |
| 60.0 Hz to 7200 Hz |
| 24.0 Hz to 7200 Hz |
| 50.0 Hz to 7200 Hz |
| 25.0 Hz to 7200 Hz |
| HD / Normal / Cinema1 / Cinema2 / Still Like |
- ATW : 3200 K, 5600 K (ATW Speed 3-stage variables.)
- AWB : AWB-A / AWB-B
- VAR (selectable between 2000 K and 15000 K by designating a value)
|
| OFF, -99 ％ to 99 % |
| 2160/29.97p (Native), 2160/25p (Native), 2160/24p (Just), 2160/23.98p (Native) |
1080/59.94p, 50p, 1080/59.94i, 50i, 1080/29.97p (Native), 25p (Native),
23.98p (over59.94i), 1080/24p (Just), 23.98p (Native), 720/59.94p, 50p |
| DC 12 V IN |
HDMI 1.4 connector, 4:2:2/10bit
• HDCP is not supported.
• Viera Link is not supported. |
| LAN terminal for IP control (RJ-45) |
| CONTROL IN RS422A (RJ-45) |
AAC compatibility (compatible with IP only)
Φ3.5 mm stereo mini jack
• During MIC input
Input level: -40 dBV (0 dB=1 V/Pa, 1 kHz)
Supply voltage: 2.5 V±0.5 V (plug-in power compatible)
"• Input impedance: Approx. 2 kΩ (when plug-in power is turned ON)
Approx. 20 kΩ (when plug-in power is turned OFF)"
• During LINE input
Input level: -10 dBV
Input impedance: Approx. 3 kΩ
• Input volume variable range: -36 dB to 12 dB (3 dB step)
• Embedded audio output level: -12 dBFS
• Sampling frequency: 48 kHz |
• If you have a PoE+ ethernet hub
LAN cable*5 (category 5e or above, straight cable) Max 100 m (328 ft)
• If you don't have a PoE+ ethernet hub
LAN cable*5 (category 5e or above, straight cable) Max 100 m (328 ft) |
| • LAN cable*5 (category 5e or above, straight cable) Max 1000 m (3280 ft) |
| Stand-alone (Desktop) or suspended (Hanging)*6 |
Speed range: 0.08°/s to 60°/s (Normal mode)*7
• 3 speed modes installed
Normal:60°/s, Fast1:90°/s, Fast2:180°/s |
| ±175° |
| -30°to 90°*8 |
| NC25 or less |
| *9 |
Windows 10
Windows® Internet Explorer® 11 (32 bit / 64 bit)
Microsoft Edge
Google Chrome |
Mac OS v11.0.1 / Safari 14.01
Mac OS v11.0.1 / Google Chrome
Mac OS v10.15 / Google Chrome
Mac OS v10.14 / Google Chrome |
iOS
Safari
iPadOS |
Android OS
Google Chrome |
| JPEG (MJPEG), H.264, H.265, NDI®|HX version 2*10,11,12,13 (H.264) |
| 1920x1080, 1280x720, 640x360, 320x180nt |
Frame rate: Maximum 30fps
Image quality (Fine / Normal) |
|
Transmission Type: Unicast port (AUTO), Unicast port (MANUAL), Multicast port
Transmission Priority: Constant bit rate, Frame rate, Best effort
Frame Rate: [60 Hz] 5fps / 15fps / 30fps / 60fps, [50 Hz] 5fps / 12.5fps / 25fps / 50fps
Max Bit Rate: 512kbps / 768kbps / 1024kbps / 1536kbps / 2048kbps / 3072kbps / 4096kbps / 6144kbps / 8192kbps / 10240kbps /
12288kbps / 14336kbps / 16384kbps / 20480kbps / 24576kbps
|
Transmission Type: Unicast port (AUTO), Unicast port (MANUAL), Multicast port
Transmission Priority: Constant bit rate, Frame rate, Best effort
Frame Rate: [60 Hz] 30fps / 60fps, [50 Hz] 25fps / 50fps
Max Bit Rate: 512kbps / 768kbps / 1024kbps / 1536kbps / 2048kbps / 3072kbps / 4096kbps / 6144kbps / 8192kbps / 10240kbps /
12288kbps / 14336kbps / 16384kbps / 20480kbps / 24576kbps |
| AAC-LC, 48 kHz / 16 bit / 2ch |
| TCP/IP, UDP/IP, HTTP, HTTPS, DNS, NTP, DHCPv6, RTP, MLD, ICMP, ARP, RTMP, SRT |
| TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP, DHCP, DNS, DDNS, NTP, IGMP, ICMP, ARP, RTMP, RTMPS, SRT |
| NDI®|HX version 2 : Upgradable |
| 1920x1080, 1280x720 |
| Transmission Type: TCP/UDP, Unicast/Multicast |
| AAC-LC, 48 kHz, 16 bit, 2 ch |
| Displayed on the AW-RP150GJ and AW-RP60GJ sides |
| Supported*14 |
| ON/OFF control |
| Possible |
| New Direct Drive System |
OIS 2-axis
MENU switching: Select between Off/O.I.S. |
The lens surface faces backward when standing by (ON/OFF)
* Default is OFF |
| red / green |
