Epiphan AV.io 4K HDMI to USB 4K capture card

Product Overview

The Epiphan AV.io 4K is a plug-and-play HDMI to USB 4K capture card that brings HDMI video and audio into a computer over USB 3.0 with no driver installation. Built for AV professionals and integrators who need a portable 4K USB video grabber for streaming, recording, and conferencing, it is auto-detected as a UVC device on Windows, macOS, and Linux. It captures resolutions up to 4096 x 2160 with near-zero latency for live HDMI capture into OBS, Wirecast, Teams, Zoom, and other capture software.

Product Description

The AV.io 4K connects an HDMI source to your computer through a single USB 3.0 connection. Because it is a UVC class device, all three major operating systems auto-detect it on connection, so there is nothing to install. It captures HDMI video at up to 4096 x 2160 (DCI 4K), streaming 4K UHD at 30 fps and 1080p at 60 fps, and it can pass video through at its native resolution or scale it up or down on output to match the resolution your software expects.

The card adds only one to two frames of latency, making it suitable for live production where on-screen lag would be noticeable. It captures PCM audio embedded over HDMI at up to 24-bit 96 kHz and outputs two-channel stereo with automatic resampling at 48 kHz, encoded in 16-bit. A metal enclosure, LED status indicators, and included HDMI and USB cables make it ready for repeated field and rack use.

For SDI sources, compare the AV.io SDI+; for 1080p HDMI capture at a lower price point, see the AV.io HD+. For internal PCIe capture, the DVI2PCIe Duo is available in the Epiphan collection.

Key Features

• 4K HDMI capture — The card captures HDMI input at resolutions up to 4096 x 2160 (DCI 4K) for high-resolution streaming and recording.
• Plug-and-play UVC operation — It is auto-detected on Windows, macOS, and Linux with no driver installation required.
• USB 3.0 connection — A single USB 3.0 link carries 4K video and audio to any compatible computer.
• Near-zero latency — With only one to two frames of latency, the card suits live production and real-time monitoring.
• On-board scaling — Output can be scaled up or down to match the resolution your capture software expects.
• Embedded audio capture — It captures PCM audio over HDMI up to 24-bit 96 kHz, output as 48 kHz 16-bit stereo.
• Broad software compatibility — As a UVC source, it works with OBS, Wirecast, Zoom, Microsoft Teams, and other capture applications.
• Rugged metal enclosure — A tough metal exterior and LED status indicators support reliable repeated use.

Typical Applications

• Broadcast studio and live event 4K capture workstations
• Conference room and boardroom video conferencing input
• Lecture capture and training room recording
• House of worship streaming and recording
• Huddle room and meeting space USB capture for Teams and Zoom
• Auditorium and multi-purpose room production systems

Technical Specifications

Frequently Asked Questions

Do I need to install drivers for the AV.io 4K?

No. The AV.io 4K is a UVC class device, so Windows, macOS, and Linux auto-detect it when you connect it over USB. There is no driver to install.

What software works with the AV.io 4K?

Any application that accepts a USB video source works, including OBS, Wirecast, Microsoft Teams, and Zoom. The card appears as a standard webcam-style video input.

How does it fit into an AV system?

Connect your HDMI source to the AV.io 4K and connect the card to a computer with a USB 3.0 port. The card delivers video and audio to your capture, streaming, or conferencing software for recording or live output.

What resolution and frame rate can it capture?

It captures up to 4096 x 2160 (DCI 4K), with 4K UHD at 30 fps and 1080p at 60 fps, and can scale the output to match your software requirements.

What warranty and support are available?

Epiphan AV.io 4K includes a one-year limited warranty with complimentary phone support. Extended multi-year SupportPlans with advanced replacement are also offered. Contact Creation Networks for current options.
