SurgeX SX-AX20E-15L Axess Elite Surge Eliminator and Power Conditioner, IP Connected, Includes AE Software

Product Overview

The SurgeX SX-AX20E-15L Axess Elite is a 1RU rack-mount IP power management system that combines 20-amp surge elimination with a 15-foot locking power cord — engineered for commercial AV installations where a secure, pull-resistant connection between the rack and wall outlet is required. Rated at 20 amps and 120 volts, this IP-connected surge eliminator and power conditioner provides the complete Axess Elite feature set: Advanced Series Mode® surge elimination, eight individually controllable outlets, real-time energy monitoring, and Crestron/AMX integration. The locking cord connector prevents accidental disconnection in high-traffic equipment rooms, rack closets, and broadcast facilities where equipment density and cable management demand a positive-lock power input. The SX-AX20E-15L is the preferred choice for AV integrators who require both extended cord reach and a secured connection point.

Product Description

The SX-AX20E-15L is functionally identical to the SX-AX20E-15, with one critical difference: the 15-foot input cord terminates in a locking connector that locks into the wall outlet or power distribution unit, preventing accidental pull-out. This feature is particularly valuable in broadcast studios, government facilities, auditoriums, and commercial AV installations where equipment racks may be accessed frequently and where an unexpected power disconnect could disrupt operations or damage equipment.

Eight switched outlets — six NEMA 5-15R and two NEMA 5-20R — are individually controllable from the built-in web GUI, via SNMP, or through the SDxP API. Each outlet supports independent power sequencing, scheduling, and AutoPing-triggered automatic reboots. Advanced Series Mode® surge elimination delivers 0V let-through on surges up to 6000V using non-sacrificial components, ensuring the unit maintains full protection throughout its operational life without maintenance or replacement after surge events.

SurgeX ICE® Inrush Current Elimination on receptacles 1 and 2 prevents high-draw devices — projectors, power amplifiers, large displays — from causing inrush current disruptions during power-up sequences. COUVS® over/under voltage shutdown protects all connected equipment by automatically disconnecting loads when input voltage falls outside safe thresholds. The included AE software provides centralized management of multiple Axess Elite master and expansion units across a facility from a single interface.

Key Features

• 15-Foot Locking Power Cord — Captive locking input cord secures the connection at the wall outlet or PDU, preventing accidental disconnection in high-traffic or high-density rack environments.
• Advanced Series Mode® Surge Elimination — 0V let-through on a 6000V surge with non-sacrificial, maintenance-free components that deliver permanent protection.
• IP-Addressable Outlet Control — Eight individually switched and sequenceable outlets controllable via web GUI, SNMP, or Crestron/AMX control systems.
• SurgeX ICE® Inrush Current Elimination — Protects high-draw equipment on receptacles 1 and 2 from inrush current during power-up, preventing circuit disruptions.
• Impedance Tolerant EMI/RFI Filtering — Up to 50 dB normal-mode attenuation for clean, conditioned power delivery to sensitive AV, audio, and video equipment.
• COUVS® Over/Under Voltage Shutdown — Automatically disconnects all loads when input voltage exceeds or falls below safe operating limits to protect connected equipment.
• Real-Time Power and Energy Monitoring — Continuous tracking of current draw, input voltage, rack temperature, and energy consumption with historical log data.
• AutoPing Automatic Reboot — Scheduled device health checks with automatic outlet power-cycling for unresponsive equipment, reducing on-site service calls.
• AE Software Included — Centralized facility management software for monitoring and controlling multiple Axess Elite units from a single interface.
• Expansion Unit Support — Master unit controls downstream SurgeX expansion units for scalable power management across larger AV systems.
• Magnetic Shielding Steel Enclosure — 1RU rack-mount steel chassis provides EMI shielding and long-term durability in commercial installation environments.

Typical Applications

• Boardroom
• Conference room
• Broadcast studio
• Government space
• Auditorium
• Training room
• Commercial meeting space
• Multi-purpose room
• House of worship

Technical Specifications

Frequently Asked Questions

What distinguishes the SX-AX20E-15L from the SX-AX20E-15?

The SX-AX20E-15L and SX-AX20E-15 are identical in electrical specifications and features. The only difference is the input cord: the SX-AX20E-15L uses a locking connector that secures to the wall outlet or PDU to prevent accidental disconnection. Choose the 15L when your installation environment requires a pull-resistant power connection.

Why is a locking power cord important in commercial AV installations?

In broadcast studios, government facilities, and high-density rack rooms, accidental cord pull-out can interrupt an entire AV system mid-operation. A locking cord provides a secured connection that requires a deliberate action to disconnect, protecting against unintentional power loss.

Can the SX-AX20E-15L integrate with Crestron or AMX?

Yes. The unit supports SNMP and the SDxP API, providing full compatibility with Crestron, AMX, and other major control systems. The included AE software adds a layer of centralized management for multi-unit deployments across a facility.

How does the SX-AX20E-15L protect against surges without degrading?

Advanced Series Mode® technology eliminates surge energy using a series circuit topology rather than absorbing it in sacrificial components like MOVs. The result is 0V let-through on surges up to 6000V, with no component wear after each event and no maintenance required over the product lifecycle.

What is the total load capacity of the SX-AX20E-15L?

The unit is rated for a total system load of 20 amps at 120 volts. Individual outlets are rated at 15 amps, with two NEMA 5-20R outlets capable of accepting 20-amp plugs. Total connected load across all eight outlets must not exceed 20 amps.

Does the SX-AX20E-15L support power sequencing?

Yes. Each of the eight outlets can be assigned a power-on delay sequence, allowing AV system components to power up in a controlled order — for example, ensuring amplifiers power on after source devices to prevent pop or thump through speaker systems.

Is the SX-AX20E-15L suitable for a broadcast or government facility?

Yes. The locking cord, non-sacrificial surge protection, COUVS® voltage shutdown, and IP-based remote management make the SX-AX20E-15L well-suited for broadcast studios and government spaces where power reliability and remote control capability are critical requirements.
