SurgeX SX-AX20E-15 Axess Elite Surge Eliminator and Power Conditioner, IP Connected, Includes AE Software

Product Overview

The SurgeX SX-AX20E-15 Axess Elite is a 1RU rack-mount IP power management system that combines 20-amp surge elimination with a 15-foot captive power cord — designed for commercial AV installations where the distance between the equipment rack and the wall outlet exceeds the reach of a standard cord. Rated at 20 amps and 120 volts with eight individually controlled outlets, this IP-connected power conditioner delivers the full Axess Elite feature set including Advanced Series Mode® surge elimination, real-time energy monitoring, and Crestron/AMX integration. The integrated 15-foot cord eliminates the need for an extension cable in deeper equipment rooms, server closets, and large rack installations, maintaining a clean and code-compliant power path. It is an ideal power conditioning and management solution for AV integrators deploying systems in boardrooms, training rooms, and broadcast studios.

Product Description

The SX-AX20E-15 shares the core architecture of the standard SX-AX20E but ships with a permanently attached 15-foot power cord in place of a short captive cord, addressing a common field requirement in commercial AV rack installations where wall outlet placement is not directly behind the rack. The unit provides eight switched outlets — six NEMA 5-15R and two NEMA 5-20R — all individually controllable via the built-in web interface, SNMP, or third-party control systems.

Advanced Series Mode® surge elimination technology ensures 0V let-through on surges up to 6000V, a level of protection that renders standard MOV-based suppressors obsolete in demanding AV environments. The technology uses non-sacrificial components, meaning the unit maintains full protection after every surge event without requiring replacement or maintenance.

SurgeX ICE® Inrush Current Elimination on receptacles 1 and 2 protects projectors, displays, and power amplifiers from inrush current damage during power-up sequences. COUVS® catastrophic over/under voltage shutdown disconnects all loads automatically if input voltage drifts outside safe operating limits. Real-time data including current draw, rack temperature, and energy consumption is logged continuously and accessible via the onboard GUI or through the included AE software. The AutoPing function enables scheduled device health checks with automatic outlet reboot for unresponsive equipment, reducing on-site service requirements.

Key Features

• 15-Foot Captive Power Cord — Integrated 15-foot input cord eliminates the need for extension cables in larger equipment rooms, rack closets, and broadcast environments.
• Advanced Series Mode® Surge Elimination — 0V let-through on a 6000V surge with non-sacrificial components for permanent, maintenance-free protection.
• IP-Addressable Outlet Control — Eight individually switched outlets controllable via web GUI, SNMP, or Crestron/AMX control systems.
• SurgeX ICE® Inrush Current Elimination — Eliminates inrush current spikes on receptacles 1 and 2 for safe power-up of high-draw AV devices.
• Impedance Tolerant EMI/RFI Filtering — Up to 50 dB normal-mode attenuation delivers clean, conditioned power to sensitive audio and video equipment.
• COUVS® Over/Under Voltage Shutdown — Disconnects all loads when input voltage exceeds or falls below safe thresholds, protecting connected equipment.
• Real-Time Energy Monitoring — Continuous logging of current draw, voltage, rack temperature, and energy consumption with historical data export.
• AutoPing Automatic Reboot — Scheduled network pings detect unresponsive devices and trigger automatic outlet power cycles to restore operation.
• AE Software Included — Facility-wide management software for centralized monitoring and control of multiple Axess Elite units.
• Expansion Unit Support — Controls downstream SurgeX expansion units from the master unit for scalable rack power management.
• Magnetic Shielding Steel Enclosure — 1RU chassis provides structural rigidity and EMI shielding for commercial rack environments.

Typical Applications

• Boardroom
• Conference room
• Training room
• Broadcast studio
• Commercial meeting space
• Government space
• Multi-purpose room
• House of worship
• Auditorium

Technical Specifications

Frequently Asked Questions

Why choose the SX-AX20E-15 over the standard SX-AX20E?

The SX-AX20E-15 is the correct choice when the equipment rack is more than a few feet from the wall outlet. Its 15-foot captive cord eliminates the need for a separate extension cable, which can introduce additional resistance, code compliance concerns, or warranty issues in commercial installations.

Is the power cord on the SX-AX20E-15 a locking type?

No. The SX-AX20E-15 uses a standard 15-foot captive cord without a locking connector. If a locking cord is required for your installation, refer to the SX-AX20E-15L, which includes a locking input cord for secure rack connections.

Can the SX-AX20E-15 be integrated with a room control system?

Yes. The SX-AX20E-15 supports SNMP and the SDxP API and is compatible with Crestron, AMX, and other major control systems. The included AE software provides an additional management interface for standalone or multi-unit deployments.

How does Advanced Series Mode® differ from MOV-based surge protection?

MOV-based suppressors absorb surge energy by clamping voltage, degrading with each event and potentially introducing ground contamination. Advanced Series Mode® uses a series circuit topology to eliminate surge energy entirely, resulting in 0V let-through, no ground contamination, and no component degradation over time.

What is the maximum load per outlet on the SX-AX20E-15?

Each outlet is rated at 15 amps maximum, subject to the 20-amp total system limit. The two NEMA 5-20R outlets can accept 20-amp plugs directly. Total connected load across all eight outlets must not exceed 20 amps.

Does the SX-AX20E-15 support remote reboot of connected devices?

Yes. The AutoPing feature sends scheduled network pings to connected devices and automatically power-cycles an outlet if the device becomes unresponsive, providing remote reboot capability without manual intervention.

Where can I purchase the SX-AX20E-15?

The SX-AX20E-15 is available from Creation Networks at creationnetworks.net. Our team provides pre-sales AV system integration consultation and post-sale technical support for all SurgeX products.
