SP746PU – Peerless-AV SmartMount Pivoting Wall Mount for 32" to 50" Displays
The Peerless-AV SP746PU is a pivoting wall mount from the SmartMount line, designed for 26"–46" flat-panel displays weighing up to 80 lb, offering a 90° side-to-side swivel and 12.55" of arm extension for versatile screen positioning without full articulation.
Product Description
The SP746PU fills the space between a fixed wall mount and a full-motion articulating arm. Where fixed mounts offer no positional flexibility and articulating mounts provide more range than many installations require, the SP746PU’s pivoting design gives integrators the ability to shift screen orientation left or right by 90° — useful for corner installations, open-plan office environments, or any location where the display needs to address more than one viewing area.
The arm extends up to 12.55" (31.9 cm) from the wall, providing sufficient clearance to access rear panel connections during installation or maintenance without fully removing the display. A 1-touch tilt mechanism delivers +15°/-5° of tilt adjustment, reducing glare from overhead lighting without requiring tools. Post-installation roll leveling of ±5° accommodates minor wall imperfections, and integrated cable management channels keep signal and power cables organized along the arm.
The SP746PU is compatible with VESA mounting hole patterns up to 400×400 mm and is manufactured in the United States. The integrated cable management system routes cables internally, eliminating the need for external cable covers or raceways and providing a finished appearance appropriate for corporate, retail, and hospitality spaces.
Key Features
- 90° side-to-side swivel allows the display to address multiple viewing zones from a single mounting point.
- Arm extends up to 12.55" (31.9 cm) from the wall for access to rear panel connections.
- 1-touch tilt mechanism provides +15°/-5° tilt adjustment without tools for quick glare reduction.
- Post-installation roll leveling of ±5° corrects for uneven wall surfaces after display installation.
- Supports displays from 26" to 46" (66–116 cm) weighing up to 80 lb (36 kg).
- Compatible with VESA mounting hole patterns up to 400×400 mm.
- Integrated cable management routes cables along the arm for a clean, finished installation.
- Manufactured in the United States.
Technical Specifications
| Specification | Value |
|---|---|
| Model Number | SP746PU |
| Compatible Display Size | 26" – 46" (66 – 116 cm) |
| Maximum Load Capacity | 80 lb (36 kg) |
| Extension from Wall | Up to 12.55" (31.9 cm) |
| Swivel Range | 90° side-to-side |
| Tilt Range | +15° / -5° (1-touch mechanism) |
| Roll Adjustment | ±5° |
| VESA Compatibility | Up to 400×400 mm |
| Cable Management | Integrated |
| Country of Origin | United States |
