Using a Shure MXA910 / MXA310 network audio microphone for a Zoom Room

This article covers Dante network audio:

• How to prepare your network
• How to enable network audio
• How to connect the Dante microphones

• Zoom Rooms
  • PC: global minimum version or higher
  • macOS: global minimum version or higher
• Zoom Rooms Controller
  • Android: global minimum version or higher
  • iOS: global minimum version or higher
• Shure MXA920 or MXA310 microphone
• Zoom Room license

Review the following necessary:

• Audio Over IP for IT Managers
• Dante Domain Manager

To ensure smooth functioning, ensure the Zoom Rooms and Dante devices are connected to the same wired network without relying on a WiFi network. It is advisable to create a separate Dante-enabled network switch and a USB-to-ethernet converter to isolate your AV network. This will allow the Zoom Rooms to access the local and building networks for external use. If an isolated AV network is not feasible, you can set up VLANs or Dante Domain Manager to regulate and control network access to your microphones.

When using this feature, the customer is always responsible for the network's security.

Note: Take every precaution possible, as there is no built-in encryption between Shure and Zoom Rooms devices. For full encrypted audio designs with networked audio, see:

• ProAV Production Studio (Up to 5 People) - MXA310
• ProAV Boardroom (9-22 People) - MXA910

1. Sign in to the Zoom web portal.
2. Click Room Management, then click Zoom Rooms.
3. Click Account Settings then find the Devices heading. Click the toggle for Enable network audio devices to turn on this setting for your entire account. Alternatively, you can edit a specific area in your location hierarchy or a specific zoom room and enable the setting.

1. Connect your microphone to the network PoE switch
2. Configure Dante routing to use the microphone for your Zoom room.
3. Tap Settings on your Zoom room controller, then tap Microphone.
4. Tap Network Audio Device and then tap See Details.
5. Tap the microphone you want on the menu to select it, then tap Done.

Learn more: ProAV Hardware Design Guides
