ZeeVee Z4KDPENCF3U ZyPer4K Extended HDMI 2.0 & Display Port Fiber Encoder with USB

Product Overview

The ZeeVee Z4KDPENCF3U is a ZyPer4K SDVoE fiber encoder combining HDMI 2.0, DisplayPort 1.3 input, and USB 2.0 extension over 10Gb multimode fiber up to 300 meters. It is the fiber, USB-equipped variant in the ZyPer4K Extended encoder family, serving as the optimal SDVoE DisplayPort encoder with KVM capability for long-distance deployments. The unit integrates with the ZyPer Management Platform for routing, video wall, and multiview management across the full SDVoE network.

Product Description

The Z4KDPENCF3U extends the ZyPer4K Extended encoder platform with both fiber connectivity and USB 2.0 peripheral extension. It accepts HDMI 2.0 or DisplayPort 1.3 input and transmits uncompressed 4KP60 4:4:4 video over 10Gb SFP+ multimode fiber with a maximum distance of 300 meters, accommodating campus-scale AV distributions where copper cabling is impractical. The integrated USB 2.0 port enables keyboard, mouse, and peripheral sharing across the SDVoE network, making this unit particularly well-suited for KVM-over-IP applications in control rooms and NOCs with fiber infrastructure. ZyPer Management Platform provides centralized routing management, up to 15x15 video wall configurations, and multiview layouts supporting up to 19 simultaneous sources. HDCP 2.2 and AES-128 encryption are standard across the platform. RS-232 (9-pin D-sub, 115.2 kbps) and IR (3.5mm) pass-through ensure full third-party control system compatibility. Power consumption is approximately 9W per unit.

Key Features

• HDMI 2.0 + DisplayPort 1.3 Input — Connects to either source connector type without adapters.
• USB 2.0 Extension — Extends USB peripherals over the SDVoE network alongside 4K video.
• 10Gb Multimode Fiber (SFP+) — Reaches up to 300m, suitable for campus and multi-building installations.
• Uncompressed 4KP60 4:4:4 — Full-resolution, zero-latency 4K video transport.
• Video Wall: 15x15 — Large-format video wall support via ZMP.
• Multiview: 19 Sources — Flexible multiview layouts on a single display.
• HDCP 2.2 + AES-128 Encryption — Content protection and secure network transport.
• RS-232 & IR Pass-Through — Compatible with Crestron, AMX, and similar control systems.
• ~9W Power Consumption — Suitable for high-density, scalable deployments.
• 3-Year Warranty — ZeeVee standard commercial coverage.

Typical Applications

• Campus-wide KVM-over-IP with 4K video over fiber infrastructure
• Control rooms and NOCs requiring USB peripheral sharing over long fiber runs
• University AV distribution with DisplayPort workstations and fiber backbone
• Multi-building enterprise deployments with distances exceeding 100m
• Government facilities with encrypted, long-distance AV-over-IP requirements

Technical Specifications

Competitor Comparison

Frequently Asked Questions

What distinguishes the Z4KDPENCF3U from the Z4KDPENCF3?

The Z4KDPENCF3U adds a single USB 2.0 port for peripheral extension over the SDVoE network. All video, audio, control, and fiber specifications are identical to the Z4KDPENCF3.

What USB devices can be extended over the fiber network?

Standard HID devices (keyboard, mouse) and most USB 2.0 peripherals are supported. High-bandwidth USB devices may have performance limitations. Verify specific device compatibility with ZeeVee before deployment.

Can I mix this unit with copper ZyPer4K encoders on the same ZMP network?

Yes. Fiber and copper ZyPer4K endpoints are managed identically within ZMP and can share the same SDVoE network when connected through a compatible 10GbE switch.

What SFP+ transceivers are compatible?

Refer to ZeeVee's current SFP+ compatibility list for validated multimode transceiver options. Using non-validated transceivers may affect performance or void warranty coverage.

Is this unit appropriate for installations over 300m?

No. The Z4KDPENCF3U supports multimode fiber to a maximum of 300 meters. For longer distances, singlemode fiber options or signal regeneration may be required. Contact ZeeVee for extended-distance deployment guidance.
