LG LSCA039-RKL – 3.91mm Left-Cut LED Cabinet

Product Overview

The LG LSCA039-RKL is the left-cut corner cabinet in LG's Versatile Series indoor direct view LED signage line, engineered for 90 degree corner LED video wall builds at a 3.91mm pixel pitch. It lets AV integrators continue a fine pitch LED display cleanly around right-angled structures rather than breaking the canvas at a column. Rated at 1,000 nits, the commercial-grade cabinet stays legible in bright lobbies, retail floors, and broadcast sets. Front or rear serviceability keeps maintenance practical in constrained corner installations.

Product Description

The LSCA039-RKL is the left-side cabinet of LG's 90 degree corner option for the Versatile Series. Paired with the right-cut counterpart, it forms a continuous wrap so indoor direct view LED signage can turn corners without an unsightly seam or gap. The cabinet shares the platform's 3.91mm pixel pitch, 14-bit processing, and 6,088 pixels per square foot density, preserving image consistency where the wall changes plane. Front and rear access allows module and component replacement in the field, an important consideration for corner positions that can be hard to reach. The IP30-rated chassis is intended for protected indoor commercial environments such as conference room feature walls, corporate lobbies, and government spaces. Build the flat sections with the LG LSCA039-RK standard cabinet and complete the opposite corner face with the LG LSCA039-RKR right-cut cabinet.

Key Features

• Left-Cut Corner Cabinet — This cabinet forms the left face of a 90 degree corner so the video wall wraps columns and right-angled structures cleanly.
• 3.91mm Pixel Pitch — The fine pitch maintains smooth, high-resolution imagery through the corner transition.
• 1,000 Nit Brightness — High output keeps content legible in brightly lit commercial interiors.
• Front and Rear Serviceability — Either-side access simplifies module replacement in hard-to-reach corner positions.
• 14-Bit Processing — Deep grayscale processing keeps color and gradients consistent across adjoining faces.
• IP30 Rated Chassis — The ingress rating suits protected indoor commercial installations.

Typical Applications

• Conference room and boardroom corner feature walls
• Commercial meeting space and multi-purpose room signage
• Broadcast studio wrap-around backdrops
• Government space and command center displays
• Auditorium and all-hands room presentation walls

Technical Specifications

Frequently Asked Questions

What is the difference between the RKL and RK cabinets? The RK is the standard flat cabinet for straight runs, while the RKL is the left-cut cabinet used to form one face of a 90 degree corner.

Do I need both the RKL and RKR for a corner? A full 90 degree corner uses the left-cut and right-cut cabinets together so the LED surface meets cleanly at the angle.

Can I mix corner and flat cabinets in one wall? Yes. Flat sections use the standard RK cabinet and the corner faces use the RKL and RKR cabinets, all sharing the same 3.91mm pitch.

How is a corner cabinet serviced? Front and rear access lets a technician replace modules or internal components from whichever side the corner installation permits.

What warranty and support are available? LG commercial direct view LED products are backed by LG's commercial warranty and service programs; contact our team for current terms and project support.
