Crestron DIN-CENCN-2-POE – DIN Rail Cresnet PoE Hub, 2 Ports

Product Overview

The Crestron DIN-CENCN-2-POE is a DIN rail-mounted Cresnet Power over Ethernet (PoE) hub providing 2 Cresnet bus ports with Power over Cresnet (PoC) injection for powering Cresnet devices from an Ethernet PoE source rather than from the 4-Series control processor’s Cresnet bus power output. It enables Cresnet devices — keypads, occupancy sensors, and other Cresnet peripherals — to receive power from the building PoE Ethernet infrastructure rather than from the control system processor’s Cresnet bus, extending Cresnet device deployment reach without consuming the processor’s Cresnet power budget.

Key Features

• 2-Port Cresnet PoE Hub: Provides 2 Cresnet ports with Power over Cresnet injection — allows Cresnet devices on these ports to be powered from PoE infrastructure rather than processor Cresnet bus power.
• DIN Rail Mounting: Snaps onto standard 35mm DIN rail in the DIN-EN-6X18 enclosure alongside DIN-AP4 and other Crestron DIN rail modules.
• PoE Input: Receives PoE power from a compatible PoE switch or injector to power connected Cresnet devices.
• Cresnet Bus Connectivity: Standard Cresnet data bus connects to the 4-Series control processor for device communication alongside the separate PoE power path.

Technical Specifications

Competitor comparison: not applicable for this product.

Frequently Asked Questions

When should I use the DIN-CENCN-2-POE instead of relying on the DIN-AP4 Cresnet bus power?
Use the DIN-CENCN-2-POE when the total Cresnet device power draw exceeds the DIN-AP4’s onboard Cresnet power budget, or when you want to use PoE infrastructure to power remote Cresnet devices independent of the processor power budget. Contact Creation Networks for Cresnet power planning guidance.

What is the warranty?
Crestron provides a standard 3-year limited warranty. Contact Creation Networks for warranty details.
