Description
VX 12.2Q-WH
The VX 12.2Q-WH PowerDual Full Range Loudspeaker boasts an exceptional performance-to-size ratio, and can also be configured for bi-amp operation. VX 12.2Q-WH provides a compact, yet punchy and sonically articulate solution for small-scale performance sound reinforcement, as well as more demanding background music and high-intelligibility speech applications where clarity and natural vocal reproduction are paramount. Thanks to its twin driver design and flexible mounting options, the VX 12.2Q-WH is also ideally suited for use complimenting much larger systems, making it an excellent choice for both installed and portable applications.
Features
-
Full range multi-purpose sound reinforcement loudspeaker for portable and installation applications
-
500 Watts continuous, 2,000 Watts peak power
-
12" PowerDual full range driver for point source phase coherence
-
12" low frequency driver for extended bass response
-
Q-Centric waveguide for tighter vertical or horizontal pattern control
-
Precise 75° H x 40° V dispersion for optimum coverage and forward projection
-
Ideal for FOH, floor monitor and side fill applications
-
Configurable for bi-amp operation
-
Vented and internally braced plywood enclosure
-
Finished with hard wearing semi matt white paint
-
Rugged powder coated perforated steel mesh grille
-
Blanking plate for optional VTH pole mount
-
Optional horizontal and vertical mounting yokes (available separately)
-
Integrip handles ergonomically integrated into top and bottom of cabinet
-
Neutrik speakON* NL4 and barrier strip connectors for input and link output
-
10-Year Warranty Program*
-
Designed and engineered in the U.K.
System
| Frequency response |
70 Hz - 25 kHz ±3 dB |
| Nominal dispersion |
75° H x 40° V @ -6 dB points |
| Directivity factor (Q) |
13 |
| Directivity index (DI) |
11.1 |
Power handling (IEC)
| Passive |
500 W continuous, 2,000 W peak |
| Bi-amp |
LF: 350 W continuous, 1,400 W peak |
| Sensitivity |
99 dB (1 W @ 1 m) |
Maximum SPL
| Passive |
126 dB continuous, 132 dB peak |
| Bi-amp |
LF: 123 dB continuous, 129 dB peak |
Impedance
| Passive |
8 Ω |
| Bi-amp |
8 Ω |
| Crossover Type |
Passive / Bi-amp switchable |
| Components |
1 x 12" (305 mm) constant directivity |
Enclosure
| Connectors |
2x Neutrik speakON* NL4 |
Wiring
| Passive |
Pins 1+ / 1- Input, Pins 2+ / 2- Link |
| Bi-Amp |
Pins 1+ / 1- LF, Pins 2+ / 2- HF |
| Dimensions H x W x D |
781 x 371 x 361 mm |
| Net weight |
30.5 kg (67.2 lbs) |
| Construction |
15 mm (5/8") enclosure / 18 mm (3/4") front, |
| Finish |
Semi matt black paint (white optional) |
| Grille |
Powder coated perforated steel |
| Flying hardware |
M10 x 8 flying inserts |
