Tannoy QCI 6DC IW High-Performance 6" Dual Concentric In-Wall Loudspeaker (White) - TA-QCI 6DC IW-WH
Tannoy QCI 6DC IW High-Performance 6" Dual Concentric In-Wall Loudspeaker (White) - TA-QCI 6DC IW-WH is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Tannoy QCI 6DC IW High-Performance 6" Dual Concentric In-Wall ...
Description
Audio Evolution
For over 90 years Tannoy has been a leader in the pursuit of high-fidelity sound. The most demanding audio professionals around the world rely on Tannoy loudspeakers to create music and sound we love to hear and feel. From recording and mastering engineers to broadcasters and film score composers Tannoy loudspeakers are trusted for their proven reliability, true to source accuracy and ability to reproduce sound the way the artist intended. There really is no substitute for Tannoy. Trusted by music creatives around the world, installed in the world's best venues and locations, perfect for listening at home.
The QCI range is designed with the same high standards and attention to detail as our flagship professional and hi-fi loudspeakers. They deliver high fidelity sound that is extremely natural and detailed. They have the same sonic signature and can be easily mixed and matched to make a stereo, surround or multi-room audiophile system.
Features
-
High-performance loudspeaker for in-wall installation applications
-
6" Dual Concentric driver featuring Tannoy point-source constant directivity
-
Tulip Waveguide for a smooth, uniform frequency response over a wide area of coverage unachievable with discrete, two-way designs
-
Glass fibre cone with high-excursion, rubber surround for high power handling
-
70 Watts continuous, 280 Watts peak power
-
Extremely thin bezel for discreet installation
-
Integrated single unit construction for easy installation
-
Semi matt white finish fits unobtrusively in any environment
-
Powder coated UV resistant perforated steel mesh grille with dust protection
-
Removable grille for custom painting
-
Self-aligning clamp mounting system
-
Removable Tannoy grille badge
-
Tannoy - Over 90 years of British sound heritage and innovation
Performance
| Frequency response (±3 dB) |
50 Hz – 20 kHz |
| Frequency response (-10 dB) |
30 Hz – 20 kHz |
| Sensitivity (1 W @ 1m) |
85 dB |
| Directivity factor (Q) |
4.8 averaged 1 kHz to 10 kHz |
| Directivity index (DI) |
6.8 averaged 1 kHz to 10 kHz |
Power handling (IEC)
| Average |
70 W |
| Programme |
140 W |
| Peak |
280 W |
| Recommended amplifi er power |
210 W @ 8 Ω |
| Nominal Impedance (Lo Z) |
8 Ω |
| Rated maximum SPL (1 m, Lo Z) |
107 dB |
| Average |
104 dB |
| Peak |
110 dB |
| Crossover point |
1.6 kHz |
Coverage angles
| 500 Hz |
180° horizontal, 160° vertical |
| 1 kHz |
141° horizontal, 144° vertical |
| 2 kHz |
119° horizontal, 134° vertical |
| 4 kHz |
92° horizontal, 87° vertical |
Transducers
| Low frequency diameter/material/type |
165.5 mm (6") |
| High frequency diameter/material/type |
25.4 mm (1) |
Physical
| Back can |
Option 1: BACK CAN IW: Steel, powder coating |
| Baffle |
Reflex loaded UL94 V-0 rated ABS |
| Grille |
Stee l, with weather resistant coating |
| Safety features |
— |
| Clamping design |
Security toggle clamp |
| Connectors |
Phoenix Contact terminal block |
| Dimensions (HxWxD) |
315 x 221 x 105 mm (12.4 x 8.7 x 4.1") |
| Bezel dimensions |
Square: 315 x 221 mm (12.4 x 8.7") |
| Mounting depth |
91.7 mm (3.6") |
| Hole cutout dimensions |
299 x 203 mm (11.8x8") |
| Net weight |
2.9 kg (6.4 lbs) |
| Packed quantity | |
| Included accessories |
Grille, paint mask, cutout template |
| Optional accessories |
Option 1: BACK CAN IW Option 2: PMK 6 IW |
