Tannoy PCI 6DC LP Premium Low Profile 6" Dual Concentric Ceiling Loudspeaker - TA-PCI 6DC LP-WH
Tannoy PCI 6DC LP Premium Low Profile 6" Dual Concentric Ceiling Loudspeaker - TA-PCI 6DC LP-WH is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Tannoy PCI 6DC LP Premium Low Profile 6" Dual Concentric Ceili...
Description
Studio Sound at Home
Designed to fit seamlessly into your world, the new Tannoy PCI series is the perfect premium loudspeaker for modern living. Discover a beautiful blend of innovative technology combined with sophisticated good looks that will match any décor. State of the art driver materials and Tannoy’s Unique Dual concentric driver technology combine to deliver music and film that is breathtakingly realistic and with phenomenal clarity.
Features
-
Premium, high-definition loudspeaker for ceiling installation applications
-
Low profile chassis design to offer great sound from tight space situations
-
6" Dual Concentric driver featuring Tannoy Omnimagnet technology
-
Torus Ogive waveguide for improved directivity
-
Blue Kevlar* cone with high-excursion, rubber surround for high power handling
-
3-way variable high-frequency level switch for customised performance preferences
-
70 Watts continuous, 280 Watts peak power
-
Extremely thin bezel for discreet installation
-
Includes round & square baffles for versatile application
-
Integrated single unit construction for easy installation
-
Semi matt white finish fits unobtrusively in any environment
-
Powder coated UV resistant perforated steel mesh grilles with dust protection
-
Removable grilles for custom painting
-
Self-aligning clamp mounting system
-
Optional Tannoy logo grille badge included
-
Tannoy - 90 years of British sound heritage and innovation
Specification
Processing
| Frequency response (±3 dB) |
50 Hz – 20 kHz |
| Frequency response (-10 dB) |
35 Hz – 20 kHz |
| Sensitivity (1 W @ 1m) |
86 dB |
| Nominal dispersion |
90° conical @ -6 dB point |
| Power handling (IEC) | |
| Average |
70 W |
| Programme |
140 W |
| Peak |
280 W |
| Recommended amplifier power |
210 W @ 8 Ω |
| Nominal Impedance (Lo Z) |
8 Ω |
Rated maximum SPL (1 m, Lo Z)
| Average |
104 dB |
| Peak |
110 dB |
| Crossover point |
2 kHz |
Transducers
| Low frequency diameter/ material/type |
165.5 mm (6") |
| High frequency diameter/ material/type |
25.4 mm (1") |
Physical
| Back can |
(BACK CAN S): Steel, with powder coating |
| Baffle |
Reflex loaded UL94 V-0 rated ABS |
| Grille |
N/A |
| Clamping design |
Security toggle clamp |
| Connectors |
Phoenix Contact terminal block |
| Dimensions | |
| Dimensions (HxWxD) |
114 x 241 x 241 mm (4.5 x 9.5 x 9.5'') |
| Bezel dimensions |
241 x 241 mm (9.5 x 9.5'') |
| Mounting depth |
106 mm (4.2'') |
| Hole cutout dimensions |
202 mm (8'') |
| Net weight |
2.9kg |
| Included accessories |
Circular baffle, square baffle, circular grille, square grille,circular paint mask, square paint mask, cutout template, screws(4 pcs) |
| Optional accessories |
Option 1: BACK CAN S Option 2: PMK 6" |
| Packed quantity |
1 |
