Soundtube SM82-EZ-II-WX 8" 2-way Extreme Weather Outdoor Surface Mount Speaker
Soundtube SM82-EZ-II-WX 8" 2-way Extreme Weather Outdoor Surface Mount Speaker - Black is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Soundtube SM82-EZ-II-WX 8" 2-way Extreme Weather Outdoor Surfa...
The SM82-EZ-II-WX is a cost-effective, high-efficiency surface-mount loudspeaker for distributed aplications or 8 ohm applications, featuring Weather Guard qualities that are built directly into the speaker. The SM82-EZ-II-WX incorporates a dedicated 8-inch polypropylene woofer and an offset 1-inch soft dome tweeter with waveguide to deliver superb intelligibility for background to foreground music and messaging (up to 106.0 dB max. SPL). SM82-EZ-II-WX speakers use a 64-watt low-insertion loss transformer and a six-position tap switch with a transformer bypass position. Mounting for the SM82-EZ-II-WX includes a proprietary, tool-free, low-profile Stealth™ bracket with a direct drive cam-wedge for stable and precise aiming up to 90 in one direction. IP-Rating: IP65.
*Note: If used indoors, remove the grille and take the plug out of the port for greater bass output. Port must remain plugged to maintain IP65 rating in outdoor use.
Specs
| Manufacturer | SoundTube |
|---|---|
| Manufacturer's Category | SM-EZ Economical Surface Mount |
| Height | 18.78 in / 477 mm |
| Width/Diameter | 11.65 in / 295.9 mm |
| Shipping Weight | 21 lbs / 9.5 kg |
| Carton Height | 15 in / 381 mm |
| Carton Length | 21 in / 533.4 mm |
| Carton Width | 16.75 in / 425.45 mm |
| Certifications | CE, IP65, RoHS, UL1480A |
| Enclosure Properties | Polystyrene, Ported |
| Included Accessories | Back Cover, Mounting Hardware, Port Plug, Safety Cable, Wire Gland |
| Source Inputs | 4 Pin Ceramic Terminal |
| IP Rating | IP65 |
| Coverage Angle (±6dB @ 2kHz) | 100° |
| Crossover Frequency | 2.5 kHz |
| Directivity Factor (Q) (Averaged 100Hz - 10kHz, @ 2kHz) | 5.0 and 8.0 |
| Directivity Index (DI) dB (Averaged 100Hz - 10kHz, @ 2kHz) | 5.0dB and 8.0dB |
| Frequency Response (± 10 dB) | 90 Hz - 22 kHz |
| Frequency Response (± 3 dB) | 65 Hz - 22 kHz |
| Grille Properties | Aluminum, Powder-Coated |
| Low Pass Crossover | 12 dB per octave 2nd order |
| Max. Continuous Power RMS | 64 W |
| Max. Program Power | 128 W |
| Minimum Impedance (Ω Ohms) | 8 Ω |
| Mounting Depth | 6.63 in / 168.4 mm |
| Network Type: High Pass | 12 dB per octave 2nd order |
| Nominal Impedance (Ω Ohms) | 8 Ω |
| Tweeter Driver | 1" Aluminum Dome |
| Woofer Driver | 8" Polypropylene |
| Sensitivity dB @ 1W/1M | 90 dB |
| Sensitivity dB @ 2.83V/1M | 90 dB |
| Tap Selector | Rotary Switch |
| Transformer Options | 25 / 70.7 / 100 V, 8 Ohm direct |
| Transformer Taps Max. Setting (25V/70.7V/100V) | 8W/64W/64W |
