Soundtube SM500I-II-WX 5.25" Extreme Weather Outdoor Surface Mount Spkr
Soundtube SM500I-II-WX 5.25" Extreme Weather Outdoor Surface Mount Spkr - Black is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Soundtube SM500I-II-WX 5.25" Extreme Weather Outdoor Surface M...
SoundTube®'s WX Weather Guard technology utilizes a dual layer hydrophobic material inside the speaker grille to keep water from the drivers and internal electronics in even the most extreme weather conditions. The SM500I-II-WX utilizes the patented ZeroReflection™ enclosure technology for optimal sound reproduction and cabinet rigidity as well as BroadBeam® waveguide technology to deliver a consistent dispersion pattern up to 10 kHz for maximum coverage area per speaker. The SM500I-II-WX has one 5.25 inch (133 mm) polypropylene woofer and one 1.0 inch (25 mm) convex titanium tweeter with FerroFluid™ cooling. The speakers 86.0 dB average sensitivity offers high output capabilities and reduced amplification costs and the six-position selectable tap switch for 25-, 70.7- and 100-volt applications provides easy access. The included SM500i-II-WX Stealth™ bracket mounting system with vertical and horizontal pivoting allow the SM500i-II-WX to be aimed anywhere within the installation space and the low profile enclosure design keeps the speaker close to the wall. Safety cable with speaker mounting bolt, Euroblock connector, wall mount bracket and terminal weather boot are included. IP-Rating: IP44.
Specs
| Manufacturer | SoundTube |
|---|---|
| Manufacturer's Category | SMi Surface Mount |
| Height | 11.4 in / 289.6 mm |
| Width/Diameter | 8.36 in / 212.3 mm |
| Shipping Weight | 10.5 lbs / 4.76 kg |
| Carton Height | 12.25 in / 311.15 mm |
| Carton Length | 13.5 in / 342.9 mm |
| Carton Width | 10.5 in / 266.7 mm |
| Certifications | CE, RoHS, UL1480A |
| Enclosure Properties | ABS Glass Fiber Reinforced, Injection Molded, Ported |
| Enclosure Volume | 349.6 cu in / 5728.92 cu cm |
| Included Accessories | Euroblock, Mounting Hardware, Safety Cable, Terminal Weather Boot |
| Optional Accessories | White Grille (GRL-SM500-II-WX-WH)|10" Safety Cable (AC-SM-SC10)|White Mounting Bracket (AC-SM5-II-WP-WH)|Connector (EUROBLOCK)|White Weatherboot (WEATHERBOOT-S-WH) |
| Source Inputs | 4 Pin 5.08mm Euroblock |
| IP Rating | IP44 |
| Crossover Frequency | 3.0 kHz |
| Directivity Factor (Q) (Averaged 100Hz - 10kHz, @ 2kHz) | 4.6 and 9.8 |
| Directivity Index (DI) dB (Averaged 100Hz - 10kHz, @ 2kHz) | 5.6dB and 9.9dB |
| Frequency Response (± 10 dB) | 60 Hz - 22 kHz |
| Frequency Response (± 3 dB) | 86 Hz - 22 kHz |
| Grille Properties | Aluminum, Powder-Coated, Weatherproof |
| Low Frequency Voice Coil | 1 in / 25.4 mm |
| Low Pass Crossover | 12 dB per octave 2nd order |
| Max. Continuous Power RMS | 75W |
| Max. Program Power | 150 W |
| Minimum Impedance (Ω Ohms) | 4 Ω |
| Mounting Depth | 10.48 in / 266.2 mm |
| Network Type: High Pass | 12 dB per octave 2nd order |
| Nominal Impedance (Ω Ohms) | 4 Ω |
| Tweeter Driver | 1" Convex Aluminum w/ BroadBeam® Waveguide |
| Woofer Driver | 5.25" Polypropylene |
| Sensitivity dB @ 1W/1M | 83 dB |
| Sensitivity dB @ 2.83V/1M | 86 dB |
| Tap Selector | Rotary Switch |
| Transformer Options | 25 / 70.7 / 100 V, 4 Ohm direct |
| Transformer Taps Max. Setting (25V/70.7V/100V) | 8W/64W/64W |
