Atlas Sound IP-SDH PoE+ Indoor Wall Mount IP Horn Speaker with LCD Display
Atlas Sound IP-SDH PoE+ Indoor Wall Mount IP Horn Speaker with LCD Display is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
The AtlasIED IPX Series IP-SDH indoor wall mount IP speaker with Horn and display leverage the VoIP Communication solution to extend tele-presence with enhanced audio for those environments where network-wide communication is desired and that require large speakers with high output to overcome high ambient noise areas or large spaces.
AtlasIED IP-SDH registers as a communication endpoint directly within InformaCast, and Revolution Advanced Notification applications, supporting both visual text and audio broadcast to enhance physical security while improving day-to-day communications through advanced alerting, bell schedules, pre-recorded, & scheduled announcements, while leveraging the WAN/LAN Network Architecture.
IP-SDH IP speakers with display provide equality “effective communication”.
“Under Title II of the ADA, all state and local governments are required to take steps to ensure that their communications with people with disabilities are as effective as communications with others.”
What does it mean for communication to be “effective”? Simply put, “effective communication” means that whatever is written or spoken must be as clear and understandable to people with disabilities as it is for people who do not have disabilities.
Where 3rd party notification applications are not required, the IP-SDH speakers can register as SIP devices directly to a SIP server or VoIP Communications Manager for critical alerts /public address applications.
Ideal for Corporate Applications, Education Institutions, Entertainment Complexes, Industrial Facilities, Government Buildings, Healthcare Facilities, Houses of Worship, Transportation Hubs - anywhere critical alerts / public address needs exist, and prefer using a single enterprise-class communications platform.
Features
- Natively Auto Registers as an Endpoint in GlobalControlKom®, InformaCast®, or Revolution Notification Applications
- Works with New or Existing Multicast Enabled Local Area Networks
- Compatible with SIP (Session Initiation Protocol) VoIP systems
- IEEE 802.3af or 802.3at Compliant POE/POE+
- Primary and Aux Speaker Outputs
- Emergency Alert Trigger
- Relay Output
- Aux Audio Input
- External Power Supply Option
- Dynamic or Static IP Address
Specs
Speaker Type | Horn |
Frequency Response | 600Hz - 14kHz |
Dispersion | 95˚ (-6dB, 2000Hz Octave Band) |
MAX SPL | 120dB @ 15-Watts (Peak) |
Power Rating | 12-Watts Max (802.3AF) / 25-Watts Max (802.3AT) |
THD | <0.2% |
Grille | Powder Coated Steel |
Connector Type | RJ-45 |
Height | 14.37" (365mm) |
Width | 12.87" (327mm) |
Depth | 4.18" (106mm) |
Weight | 5.21 lbs. (2.36kg) |
Shipping Weight | 6.66 lbs. (3.02kg) |
Safety Listed | 62368-1, CSA C22.2 #62368-1, IEC 62368-1 CB Scheme and FCC |
