Samsung OH85N-D 85" OHN-D Series Class 4K UHD Dual-Sided Digital Signage Display

Name: Samsung OH85N-D 85" OHN-D Series Class 4K UHD Dual-Sided Digital Signage Display
Brand: Samsung
SKU: OH85N-D
Price: 63761.00 USD
Availability: InStock

Authorized Dealer

$63,761.00 $78,475.00

Shipping calculated at checkout.

Samsung | SKU: OH85N-D

Shipping Availability*

Free Ground Shipping on Most Orders Over $250.00

The Samsung OHN-D 85" Class Full HD Dual-Sided Digital Signage LED Display is a dual display with screens on both sides, so you can maximize messaging. The window-facing screen projects clear, bright images so you can attract and engage your audience. Once inside, you can promote sales, new merchandise, and provide additional information about the store and its services on the indoor-facing screen. With two screens in one display, you can reduce equipment and installation costs and improve operational efficiency, compared to installing two separate displays. This all-in-one digital signage solution allows for easy content management and seamless playback.

Dual Display with Bright, Brilliant, Glare-Free Picture Quality

At 3000 cd/m², messages on the window-facing screen remain bright and clear even in direct sunlight in a storefront. Combined with a high 5000:1 contrast ratio, you get an uncompromised picture that can capture customers' attention and entice them into your store. And at 1000 cd/m², the indoor-facing screen delivers clear, legible images and text.

Designed for Storefront Window Displays

A slim design lets you easily mount the OM-N series display on a stand or hang it from a ceiling, so you have more options for positioning, giving you flexibility in how your valuable floor space is designed and utilized. The clean look of the display allows for customer engagement without aesthetic distraction.

All-in-One Digital Signage Solution

The embedded MagicInfo Player S6, backed by the Tizen operating system, boosts the display's performance, allows for easy content management, and helps to ensure seamless content transition and playback. All without the need for an external signage player or computer.

Samsung Circular Polarizing Technology

Samsung's circular polarizing technology allows content to be easily viewed, even by passersby wearing polarized sunglasses.

Commercial Reliability

Built to handle 24/7 continuous operation with IP5X-validated dust protection and engineering to prevent damage from overheating, you'll be able to deliver impactful messaging to your audience around the clock, while a 3-year onsite warranty secures your investment and peace of mind.

Clutter-Free Cable Management

The OMN-D series frees up space, offering retailers more room to market themselves to potential customers on both sides with one display. The display is easily activated with one electric power cord and one LAN cable, reducing cord clutter and increasing energy efficiency. A connectivity cover at the top of the display keeps connections clean and organized.

Specs

Panel

Diagonal Size85"

Type60Hz D-LED Local Dim. BLU
Resolution3840*2160 (4K UHD)

Pixel Pitch(mm)0.488 x 0.488
Active Display Area(mm)1872(H) x 1053(V)
Brightness(Typ.)3,300 (w/o glass) nit

Contrast Ratio3000:1
Viewing Angle(H/V)178/178

Response Time(G-to-G)8ms
Display Colors8 bit - 16.7 Mbit
Color Gamut72%
Operation HourN/A

Haze0%

Display

Dynamic C/R100,000:1
H-Scanning Frequency15 ~ 135KHz (HDMI), 30 ~ 135KHz (DP)
V-Scanning Frequency24 ~ 75Hz (HDMI), 30 ~ 75Hz (DP)
Maximum Pixel Frequency594MHz (HDMI), 533.25MHz (DP)

Connectivity

Input

RGBDP 1.2 (2)
VideoHDMI 2.0 (4)

HDCPHDCP 2.2
USBUSB 2.0 (2)

Output

AudioStereo Mini Jack

External ControlRS232C (In), RJ45 (In)

Power

TypeInternal
Power SupplyAC 100 - 240 V (+/- 10 %), 50/60 Hz

Power Consumption

Max[W/h]3,600 (1,800x2)

Typical[W/h]W/W(EU) 1200 (600x2)US/KOR/Etc. 2,020 (1,010x2)※ Etc: CHINA, TAIWAN, BRA

BTU(Max)12276 (6,138x2)
Sleep modeless than 1W
Off modeless than 1W

Mechanical Specification

Dimension (mm)

Set1,193 x 2,012 x 228 mm
Package1,510 x 2,284 x 577 mm (Without Pallet)

Weight (kg)

Set255kg
Package310.6kg

Operation

Operating Temperature-30 ℃ ~ 50 ℃

Humidity10 % ~ 100 % (Non-Condensing)

Feature

Key FeaturesDual Display, High Brightness, IP56 Outdoor,Built-in MagicInfo Player S6, SSSP6

OrientationN/A

Remote ControlN/A

Special FeaturesIP56 Rated Simple Enclosure Outdoor, Polarized Sun Glasses Viewable in any direction, Portrait Installation Support, Auto Brightness Control with Ambient Brightness Sensor, Temperature Sensor, RJ45 MDC, Auto Source Switching & Recovery, Clock Battery(80hrs Clock Keeping)

Internal Player

ProcessorCortex A72 1.7GHz Quad-Core CPU

On-Chip Cache MemoryL1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB

Clock Speed1.7GHz

Main Memory Interface2.5GB LPDDR4 1.5GHz 64bit

GraphicsGraphic resolution : 1920x1080 Output resolution : up to 3840x2160 (Scale up from graphic processing result.) - Supports OpenGL ES

Storage (FDM)8GB (3.88GB Occupied by O/S, 4.12GB Available)

MultimediaVideo Decoder - MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC - VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 Audio Decoder - AC3 (DD), MPEG

IO PortsUSB 2.0

Operating SystemTizen 4.0 (VDLinux)

Certification

SafetyCB (Europe) : IEC60950-1/EN60950-1 UL(USA) : cUL60950-1

EMCFCC (USA) Part 15, Subpart B Class A CE (Europe) : EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003

IP RatingIP56

Accessory

IncludedQuick Setup Guide, Regulatory Guide, Warranty Card, Remote Controller, Batteries

Optional

StandN/A

MountN/A

SpecialtyN/A

Media Player

Media PlayerN/A
