ASHLY FX500.4 4-Channel Power Amplifier with DSP, 4 x 500W at 2/4 Ohms
ASHLY FX500.4 4-Channel Power Amplifier with DSP, 4 x 500W at 2/4 Ohms is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
ASHLY FX500.4 4-Channel Power Amplifier with DSP, 4 x 500W at 2/4 Ohms
The FX Series features a powerful DSP engine that can configure to suit virtually any task, without the need for additional equipment. From processing input sources, routing and output DSP that can fine tune the sound of any speaker. Everything you need is right there. These will mix into Zones A-D and then into Outputs (2 or 4 depending on the number of amplifier channels). All models have a 4-channel DSP configuration with Input processing, Zone Processing, Output Processing, Speaker Processing and Device Settings
Features
- 500W x 4 @ 2/4 Ohms, 2 x 1000W @70/100V
- Intuitive Browser-based software Interface
- Comprehensive DSP (4 Input x 4 Output)
- Ethernet & Wi-Fi (WAP) connectivity for DSP control
- Dynamic Power Sharing-up to 2 x 750W (single channel driven @ 2 Ohms)
- Advanced Dynamic Power Sharing distributes power between channels, with 2x channel power
- Networkable via Ethernet or built-in WiFi
- Built-in advanced DSP on all inputs & outputs, including: Sensitivity, Routing, Gain, PEQ, Compressor, Limiter, FIR Filters, X-Over, Polarity & Delay
- Browser-based UI accessed via PC or mobile device. No software to install
- All models have 4 Input channels x 2 or 4 Output channels
- Auto/Manual Power Saver Mode (sleep/standby), adjustable in Software
- Customized Speaker Presets made be created, saved & loaded for each output channel
- Addressable GPIO, Standby/Mute & VC remote ports. VC assignable per channel via software
- 1/2 RU models easy to hide in “non-rack” installations
- Highly efficient Class D and lightweight
- Optional hardware for 1/2 RU models for rack & wall/surface mounting
Specs
| General Information | |
| Manufacturer | Ashly Audio, Inc |
| Manufacturer Part Number | FX500.4 |
| Manufacturer Website Address | http://www.ashly.com |
| Brand Name | Ashly |
| Product Series | FX |
| Product Model | FX500.4 |
| Product Name | FX Series 4 x 500W Amplifier with DSP |
| Product Type | Amplifier |
| Technical Information | |
| Impedance | 4 Ohm |
| Classification | D |
| Features | Digital Signal Processing |
| Audio | |
| Audio Channels | 4 |
| RMS Output Power | 2000 W |
| Network & Communication | |
| Ethernet | Yes |
| Wireless LAN | Yes |
