Tannoy CVS 8 8" Coaxial In-Ceiling Loudspeaker (Pair) - TA-CVS8
Tannoy CVS 8 8" Coaxial In-Ceiling Loudspeaker (Pair) - TA-CVS8 is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Tannoy CVS 8 8" Coaxial In-Ceiling Loudspeaker (Pair) - TA-CVS8
Description
CVS 8
The CVS 8 is a compact 240-Watt ceiling loudspeaker engineered to provide superb audio performance in both background and foreground music sound systems. Ideally suited for a wide variety of applications, from restaurants and hotels to houses of worship and businesses of all types, the CVS 8 offers the power handling, wide frequency response and low distortion more typically found in a studio reference monitor than a ceiling loudspeaker. The resulting sound is warm, with a nuanced and pristine clarity that envelopes the listener – without intruding.
Features
-
Coaxial full range ceiling loudspeaker for installation applications
-
60 Watts continuous, 240 Watts peak power
-
8" mineral loaded polypropylene driver with nitrile rubber surround for enhanced durability and long-term reliability
-
0.75" ferrofluid cooled soft dome neodymium high frequency driver
-
Wide constant directivity dispersion for optimum coverage
-
UL 1480 certified for fire-protected signalling systems
-
UL 2043 certified for air-handling spaces
-
UV and weather resistant UL 94 V-0 ABS front with plated steel fire can enclosure
-
Multiple transformer taps for 70 V and 100 V line systems or 6 Ohm direct input
-
Low insertion loss 60 W line transformer with easily accessible tapping switch
-
Semi matt white finish fits unobtrusively in any environment
-
Mounting C-ring and ceiling tile rails included
-
Powder coated perforated steel mesh grille with dust protection
-
Phoenix* connector with steel cover and strain relief clamping mechanism for fire rated cable
-
10-Year Warranty Program*
-
Designed and engineered in the U.K.
Specifications
System
| Frequency response (-3 dB)1 |
79 Hz - 21 kHz |
| Frequency response (-10 dB)1 |
60 Hz - 24 kHz |
| System Sensitivity (1 W @ 1 m)2 |
93 dB (1 W = 2.45 V for 6 Ohms) |
| Nominal Coverage Angle |
90 degrees conical |
| Coverage Angle (1 kHz to 6 kHz) |
84 degrees conical |
| Directivity Factor (Q) |
14.7 averaged 1 kHz to 6 kHz |
| Directivity Index (DI) |
11.7 averaged 1 kHz to 6 kHz |
| Rated Maximum SPL |
111 dB (average) |
| Power Handling3 |
Average: 60 W Programme: 120 W Peak: 240 W |
| Recommended Amplifier Power |
120 W @ 6 Ohms |
| Nominal Impedance |
6 Ohms |
| Transformer Taps (via front rotary switch) |
70 V: 60 W / 30 W / 15 W / 7.5 W / OFF & low impedance operation 100 V: 60 W / 30 W / 15 W / OFF & low impedance operation |
Transducers
| Low Frequency |
Coaxial 200 mm (8.00") |
| High Frequency |
19 mm (0.75") |
Physical
| Enclosure |
Back can: Zinc plated steel Baffle: Reflex loaded UL 94V-0 rated ABS Grille: Steel, with weather resistant coating |
| Safety Features |
Safety ring located at rear of enclosure for |
| Clamping Design |
Security toggle clamp |
Back Can Options
| Cable Entry Options |
Cable clamp & squeeze connector for conduit up to 22 mm |
| Connectors |
Removable locking connector with screw |
| Safety Agency Ratings |
UL-1480, UL-2043, CE |
| Hole Cutout Diameter |
320 mm (12.60") |
| Dimensions Bezel diameter |
355.6 mm (14.00") |
| Front of ceiling to rear of back can |
251.0 mm (9.88") |
| Front of ceiling to top of safety loop |
264.0 mm (10.39") |
| Net Weight (ea) |
6.6 kg (14.6 lbs) |
| Included Accessories |
C Ring, tile bridge, paint mask, |
| Optional Accessories |
Plaster (mud) ring |
