Crestron DM-NVX-E30 DM NVX® 4K60 4:4:4 HDR Network AV Encoder
Description
Crestron® DM NVX® technology transports ultra high‑definition 4K60 4:4:4 video over standard Gigabit Ethernet with no perceptible latency or loss of quality. Using standard network switches and CAT5e UTP wiring, a DM NVX system delivers a high‑performance virtual matrix routing solution for any enterprise or campus‑wide 4K content distribution application. Support for High Dynamic Range (HDR10) and HDCP 2.2 compliance ensures the ultimate in picture quality and compatibility for all of today’s varied media sources.1, 2
The Crestron® DM-NVX-E30 is a compact AV over IP encoder designed to function as a transmitter. Featuring secure web‑based control and management, an HDMI® input, an analog audio output, AES67 transmit and receive capability, and copper Ethernet connectivity with PoE+ support, the DM-NVX-E30 offers a low‑cost encoder solution for a DM NVX network AV installation of any size.2
Real‑Time 4K60 Video Distribution
Engineered for demanding conference room and classroom applications, DM NVX technology ensures real‑time, full‑motion 4K60 video performance for the presentation of multimedia, videoconferencing, and live camera images. Interactive functions such as gameplay and the use of a mouse are fluid and natural.
A DM NVX system is engineered for stability and ultimate reliability. Line‑synchronized outputs ensure perfect synchronization of content across multiple displays for applications such as digital signage. Variable Multicast TTL (Time To Live) enables traversing multiple network routers for optimal flexibility.
Key Features
- 4K60 4:4:4 video over standard Gigabit Ethernet
- HDR10, HDR10+, and Dolby Vision® video support
- Real‑time video performance over the network
- Pixel Perfect Processing technology
- Enterprise‑grade security including 802.1X, Active Directory® credential management, TLS, and AES‑128
- HDCP 2.2 compliant
- Encoder functionality for use with DM NVX® products that can function as decoders
- One HDMI® input
- Image preview
- Test pattern generator
- Fixed, adaptive, or variable bit rate
- Analog audio de-embedding
- 7.1 surround sound audio
- AES67 audio embedding and de-embedding
- Copper Ethernet connectivity with PoE+ support
- Automatic point-to-point connectivity
- Device control via RS‑232, IR, and CEC
- Easy setup via built‑in web pages
- Compatibility with Crestron® 3‑Series® or later control systems
- Streamlined management using DM NVX Director® virtual switching appliances
- .AV Framework™ technology support
- XiO Cloud® service support
- Crestron Home® OS support
- API for full control of the DM-NVX-E30
- Compact, surface‑mountable design
- Powered via PoE+ or optional power pack (sold separately)
Specs
| Encoding | ||
| Stream Type | Pixel Perfect Processing (default) or DM-NVX-D10/D20/D200 Series6 | |
| Video Resolutions | Up to 4096x2160@60Hz (DCI 4K60), 4:4:4 color sampling, HDR10, HDR10+, Dolby Vision®, and Deep Color support | |
| Audio Formats | Multichannel (up to 8-channel LPCM or encoded HBR 7.1 surround sound) | |
| Bit Rates | Fixed: 200 to 950 Mbps - user specified,3 Adaptive: Dependent on input resolution of the stream, or Variable: Less than 150 Mbps to maximum of 750 Mbps, dependent on content and input resolution of the stream |
|
| Streaming Protocols | RTP, SDP | |
| Container | MPEG-2 transport stream (.ts) | |
| Session Initiation | Multicast via secure RTSP | |
| Copy Protection | HDCP 2.3, AES-128, PKI | |
| Video | ||
| Input Signal Types | HDMI with HDR10, HDR10+, Dolby Vision, Deep Color, and 4K60 4:4:4 support1, 7 (Dual-Mode DisplayPort™ interface and DVI compatible8) | |
| Copy Protection | HDCP 2.3 | |
| Resolutions | Common resolutions are listed in the following table. | |
| Scan Type |
Resolution | Frame Rate |
Color Sampling |
Color Depth |
|---|---|---|---|---|
| Progressive | 4096x2160 DCI 4K and 3840x2160 4K UHD | 30 Hz | 4:4:4 | 12 bit |
| 60 Hz | 4:2:0 | 12 bit | ||
| 60 Hz | 4:2:2 | 12 bit | ||
| 60 Hz | 4:4:4 | 8 bit | ||
| 2560x1600 WQXGA Reduced Blanking | 60 Hz | 4:4:4 | 8 bit | |
| 2560x1440 WQHD Reduced Blanking | 60 Hz | 4:4:4 | 8 bit | |
| 120 Hz | 4:4:4 | 8 bit | ||
| 2560x1080 UWFHD | 60 Hz | 4:4:4 | 8 bit | |
| 2048x1152 QWXGA | 60 Hz | 4:4:4 | 12 bit | |
| 2048x1080 DCI 2K | 60 Hz | 4:4:4 | 12 bit | |
| 1600x1200 UXGA | 60 Hz | 4:4:4 | 12 bit | |
| 1920x1200 WUXGA | 60 Hz | 4:4:4 | 12 bit | |
| 1920x1080 FHD 1080p | 60 Hz | 4:4:4 | 12 bit | |
| 120 Hz | 4:4:4 | 8 bit | ||
| 240 Hz | 4:4:4 | 8 bit | ||
| Interlaced | 1920x1080 HD 1080i | 30 Hz | 4:4:4 | 12 bit |
| NOTE: The maximum supported resolution is 4096x2160 at 60 Hz with 4:4:4 color sampling. Custom resolutions are supported at pixel clock rates up to 600 MHz. | ||||
| Audio | ||
| Input Signal Types | HDMI (Dual-Mode DisplayPort interface compatible)8 | |
| Digital Formats | Dolby Digital®, Dolby Digital EX, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS®, DTS ES, DTS 96/24, DTS HD High Res, DTS HD Master Audio, DTS:X, LPCM up to 8 channels | |
| Analog Formats | Stereo 2-channel | |
| Digital-To-Analog Conversion | 24-bit 48 kHz | |
| AES67 | 24-bit 48 kHz | |
| Analog Performance | Frequency Response: 20 Hz to 20 kHz ±0.5 dB; S/N Ratio: >95 dB 20 Hz to 20 kHz A-weighted; THD+N: <0.005% @ 1 kHz; Stereo Separation: >90 dB |
|
| Analog Output Volume Adjustment | −80 to +20 dB | |
| Communications | ||
| Ethernet | 100/1000 Mbps, auto-switching, auto-negotiating, auto-discovery, full/half duplex, TCP/IP, UDP/IP, CIP, DHCP, SSL, TLS, SSH, SFTP (SSH File Transfer Protocol), IEEE 802.1X, IPv4 only or both IPv4 and IPv6, Active Directory authentication, variable Multicast TTL, HTTPS web browser setup and control, Crestron 3-Series or later control system integration | |
| USB | USB 2.0 computer console (for setup) | |
| RS-232 | 2-way device control and monitoring up to 115.2k baud with hardware and software handshaking (via control system); computer console (for setup) | |
| IR/Serial | 1-way device control via infrared up to 1.1 MHz or serial TTL/RS-232 (0-5 V) up to 19.2k baud (via control system) | |
| HDMI | HDCP 2.3, EDID, CEC | |
| DM NVX (via Ethernet) | HDCP 2.3, AES-128 AV content encryption with PKI authentication, RTP, secure RTSP, SDP, ONVIF, IGMPv2, IGMPv3, SMPTE 2022, FEC (Forward Error Correction) | |
| Connectors | ||
| Ethernet | (1) 8-pin RJ-45 connector, female; 100BASE-TX/1000BASE-T Ethernet port;2 PoE+ PD (powered device) port, IEEE 802.3at Type 2 PoE+ Class 4 (25.5 W) compliant, Compatible with Crestron DM-PSU-ULTRA-MIDSPAN, PoE+ compliant Ethernet switch, or approved third-party PSE5 |
|
| HDMI INPUT | (1) HDMI Type A connector, female; HDMI digital video/audio input (DVI and Dual-Mode DisplayPort interface compatible8) |
|
| AUDIO | (1) 5-pin 3.5 mm detachable terminal block; Balanced/unbalanced stereo line-level audio output;4 Output Impedance: 200 Ohms balanced, 100 Ohms unbalanced; Maximum Output Level: 4 Vrms balanced, 2 Vrms unbalanced |
|
| CONSOLE, USB | (1) Micro USB connector, female; USB 2.0 computer console port (for setup) |
|
| IR 1 – 2 | (1) 4-pin 3.5 mm detachable terminal block; Comprises (2) IR/Serial ports; IR output up to 1.1 MHz; 1-way serial TTL/RS-232 (0-5 V) up to 19200 baud; IRP2 emitter sold separately |
|
| COM | (1) 5-pin 3.5 mm detachable terminal block; Bidirectional RS-232 port; Up to 115.2k baud, hardware and software handshaking support |
|
| 24VDC 1.25A | (1) 2.1 x 5.5 mm DC power connector; 24 VDC power input; PW-2412WU power pack (sold separately) |
|
| G | (1) 6-32 screw; Chassis ground lug |
|
| Controls and Indicators | ||
| NV | (1) Green LED, indicates unit is encoding (transmitting) network video | |
| OL | (1) Green LED, indicates an online connection to a control system via Ethernet | |
| Ethernet | (2) LEDs, green indicates Ethernet link status, amber indicates Ethernet activity | |
| HDMI INPUT | (1) Green LED, indicates sync detection at the HDMI input | |
| PWR | (1) Bi-color green/amber LED, indicates operating power supplied via PoE+ or optional power pack (sold separately), lights amber while booting and green when operating | |
| SETUP | (1) Red LED and (1) push button, displays onscreen IP address | |
| RESET | (1) Recessed push button, reboots the device | |
| Power | ||
| PoE+ | IEEE 802.3at Type 2 Class 4 (25.5 W) compliant; Compatible with Crestron DM-PSU-ULTRA-MIDSPAN, PoE+ compliant Ethernet switch, or approved third-party PSE |
|
| Power Pack (Optional) |
Input: 0.8 A maximum @ 100-240 VAC, 50/60 Hz Output: 1.25 A @ 24 VDC Model: PW-2412WU (sold separately) |
|
| Power Consumption | 15 W typical | |
| Environmental | ||
| Temperature | 32° to 104° F (0° to 40° C) | |
| Humidity | 10% to 90% RH (non-condensing) | |
| Heat Dissipation | 48 BTU/hr | |
| Acoustic Noise | 33 dBA typical | |
| Enclosure | ||
| Chassis | Metal, black finish, integral mounting flanges, fan cooled; vented top, front, rear, and sides | |
| Mounting | Freestanding, surface mount, or attach to a single rack rail | |
| Dimensions | ||
| Height | 5.41 in. (138 mm) | |
| Width | 9.27 in. (236 mm) | |
| Depth | 1.15 in. (30 mm) | |
| Weight | ||
| 1.7 lb (0.77 kg) | ||
