Black Box C6PC28-BK-10 10FT BLACK CAT6 SLIM 28AWG PATC H CABLE 250MHZ UTP CM SNAGLESS

Black Box Slim-Net Cat.6 UTP Patch Network Cable - 10 ft Category 6 Network Cable for Patch Panel, Wallplate, Network Device - First End: 1 x RJ-45 Network - Male - Second End: 1 x RJ-45 Network - Male - 10 Gbit/s - Patch Cable - Gold Plated Contact - CM - 28 AWG - Black

Slim Fit

Black Box Slim-Net CAT6 patch cables feature a low-profile design that saves space and reduces clutter in crowded telecom rooms, data centers, and other high-density Gigabit networking applications. With a diameter of only .161 inches, these 28-AWG cables are almost half the size of typical 24-AWG cables. When you calculate the physical cable area in bundles and in patching connections, you actually save more than 50 percent space when compared to traditional cables.

Easier Cable Handling

Because there's more space between patched 28-AWG cables, there's more space for your fingers during installs and MACs. An added benefit is improved airflow and port visibility.

Reduced Cable Management

These 28-AWG cables have a small footprint and great flexibility, making it easy to route them without a cable manager. In addition, you can gain more than 50 percent space in vertical cable managers.

Conserve Rack Space

A major benefit of 28-AWG cables is they allow you to put more cables in high-density 1U or 2U patch panels, freeing up valuable rack units. You can also eliminate or reduce the number of horizontal cable managers, opening up even more space.

Big Performance in a Small Cable

Black Box Slim-Net cables meet ANSI/TIA-568-C.2 performance standards, ensuring the transmission of your Gigabit Ethernet signaling. They feature a robust construction that includes 50-micron gold-plated contacts for superior conductivity. These cables have connectors designed for the insertion and extraction life of 750 cycles, making for an ultra-reliable solution that you can count on to perform. They also feature snagless boots that provide extra strain relief and prevent connector damage due to cable snags during installation. Available in a variety of lengths and colors, Black Box's Slim-Net line of cabling gives you the flexibility to build your install however you want.

• Slim-Net cables feature a low-profile design to save space in high-density applications
• 28-AWG cable is nearly half the diameter of standard cabling
• This cable reduces clutter, enhances airflow and improves heat dissipation
• Cabling meets ANSI/TIA-568-C2 performance standards
• Cable tested to 250-MHz CAT6 industry standard
• 50-micron gold-plated contacts provide superior conductivity
• Snagless boots prevent connector damage due to snags during installation

Specs

Physical Characteristics
Product Color	Black
Warranty
Limited Warranty	Lifetime
Miscellaneous
Country of Origin	China
Environmentally Friendly	Yes
General Information
Product Type	Network Cable
Manufacturer Part Number	C6PC28-BK-10
Manufacturer Website Address	http://www.blackbox.com
Manufacturer	Black Box Corporation
Product Name	Slim-Net Cat.6 UTP Patch Network Cable
Product Line	Slim-Net
Brand Name	Black Box
Technical Information
Cable Length	10 ft
Data Transfer Rate	10 Gbit/s
Device Supported	Wallplate
	Patch Panel
	Network Device
Jacket Type	CM
Shielding	No
Features	Strain Relief
	Stranded
	Near End Cross Talk (NEXT)
	Damage Resistant
	Booted
Cable Characteristic	Patch Cable
Cable Type	Category 6
Connector Type on First End	RJ-45 Network - Male
Connector Type on Second End	RJ-45 Network - Male
American Wire Gauge	28 AWG
Contact Plating	Gold
Connector on First End Details	1 x RJ-45 Network - Male
Connector on Second End Details	1 x RJ-45 Network - Male
Boot Type	Snagless
