Biamp TesiraFORTÉ DAN AI Fixed I/O DSP - 911.0448.900

The TesiraFORTÉ® DAN AI is a digital signal processor that comes with 32 bi-directional channels of Dante™ digital audio, 12 analog inputs, and 8 analog outputs. It also offers up to 8 channels of customizable USB audio, enabling it to interface directly with USB audio hosts and make the most of today's advanced conferencing solutions. With its extensive audio processing capabilities, including signal routing and mixing, equalization, filtering, dynamics, and delay, as well as its control, monitoring, and diagnostic tools, the TesiraFORTÉ DAN AI is a perfect fit for small to medium-sized rooms that require premium audio solutions for voice lift and mix-minus, such as conference rooms or council chambers. All configurations can be easily done through the Tesira software.

Features

• 32 x 32 channels of Dante
• AES67-enabled Dante endpoint
• 12 mic/line level inputs, 8 mic/line level outputs
• Gigabit Ethernet port
• RS-232 serial port
• 4-pin GPIO
• 2-line OLED display with capacitive-touch navigation
• Rack mountable (1RU)
• System configuration and control via Ethernet
• Internal universal power supply
• Signal processing via intuitive software allows configuration and control for signal routing, mixing, equalization, filtering, and delay
• CE marked, UL listed, and RoHS compliant
• Covered by Biamp Systems’ five-year warranty
