Allied Telesis AT-X510-28GSX-80 24 - 100/1000 SFP PORTS 4 10G SFP+ PORTS DUAL REPLACEABLE DC

Allied Telesis AT-X510-28GSX-80 Layer 3 Switch - Manageable - 1000Base-X, 10GBase-X - 3 Layer Supported - 24 SFP Slots - Rack-mountable - 1 Year Limited Warranty



The Allied Telesis x510 Series of stackable Gigabit Layer 3 switches includes a full range of security and resiliency features, coupled with easy management, making them the ideal choice for network access applications.

Allied Telesis x510 Series switches are a high-performing and feature-rich choice for today's networks. They offer a versatile solution for enterprise applications. With a choice of 24- and 48-port models with 10Gigabit uplink ports, plus the power of Allied Telesis Virtual Chassis Stacking (VCStack™), the x510 Series can connect anything from a small workgroup to a large business.

Features

• Built-in power supply to ensure all components are being supplied with accurate voltage
• Can work as layer 3 routing for scalable network design
• Rack mounting enables you to organize wires & secure cables for professional installation
• Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
• Increases the stack bandwidth of the stack port further than that of a single port
• Layer 3 Switch ensures productivity by providing an efficient, hassle-free connection
• 512 MB memory makes you productive with its smooth performance

Specs

Network & Communication Layer Supported 3 Management & Protocols Management MIB SNMP v1, v2c, v3 Telnet CLI VLAN QoS SSH Syslog DHCP Web Based Management sFlow Manageable Yes Power Description Power Source Power Supply PoE (RJ-45) Port No Memory Flash Memory 64 MB Standard Memory 512 MB Memory Technology DDR SDRAM Miscellaneous Certifications & Standards Safety: UL60950-1 CAN/CSA-C22.2 No.60950-1-03 EN60950-1 EN60825-1 AS/NZS 60950.1 cUL TUV EMC: EN55022 class A FCC class A VCCI class A Immunity: EN55024 EN61000-3-levels 2 IEEE Standards: 802.1AX 802.2 802.3 802.3ad 802.3az 802.3u 802.3x 802.3z Country of Origin China Environmentally Friendly No Media & Performance Network Technology 10GBase-X 1000Base-X Ethernet Technology Gigabit Ethernet 10 Gigabit Ethernet Physical Characteristics Weight (Approximate) 10.58 lb Form Factor Rack-mountable Height 1.7" Width 17.3" Depth 12.8"

I/O Expansions Expansion Slot Type SFP+ SFP Number of Total Expansion Slots 28 Number of SFP Slots 24 Number of SFP+ Slots 4 Shared SFP Slot No General Information Product Type Layer 3 Switch Manufacturer Part Number AT-X510-28GSX-80 Manufacturer Website Address http://www.alliedtelesis.com Manufacturer Allied Telesis, Inc Product Model AT-X510-28GSX Product Name AT-X510-28GSX-80 Layer 3 Switch Product Series x510 Brand Name Allied Telesis Interfaces/Ports Token Ring Port No LRE Port No USB No Modular No Management Port Yes Uplink Port No Stack Port Yes Bypass No Port/Expansion Slot Details 24 x Gigabit Ethernet Expansion Slot 4 x 10 Gigabit Ethernet Expansion Slot
