- Station accepts all Microflex Wireless transmitters
- Charge status indicators: 5-segment LEDs on the unit display charge status individually for every docked microphone
- Remote charge status monitoring: Ethernet connection to the system enables remote monitoring of battery charge status in hours and minutes via the control software or third party control systems
- Transmitter linking: Assign docked wireless microphones to channels on an Access Point Transceiver by simply pressing "link"
- Rapid charge times: Reaches 50% charge in one hour and fully charges transmitters in two hours
- Overcharge protection: Smart recharging circuitry safeguards against battery damage and extends life cycles
Specification
Physical
| Charge Time | MXW1, MXW6, MXW8: 50% = 1 hour, 100% = 2 hours MXW2: 50% = 1.5 hours, 100% = 3 hours |
| Network Interface | 10/100 Mbps Ethernet |
| Power Requirement | 15 V DC @ 3.3 A maximum, supplied by external power supply (tip positive) |
| Housing | Molded plastic, cast zinc |
| Dimensions | 2.7 x 13.5 x 7.25" (68 x 343 x 184 mm) |
| Weight | 6.4 lb (2.9 kg) |
Packaging Info
| Package Weight | 9.02 lb |
| Box Dimensions (LxWxH) | 15.1 x 12.7 x 3.9" |
