Netgear GS524UP-100NAS 24-Port PoE++ Compliant Gigabit Unmanaged Network Switch
Netgear GS524UP-100NAS 24-Port PoE++ Compliant Gigabit Unmanaged Network Switch is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or just need expert advise?
Give us a call at 1-888-230-3661 or LiveChat below.
Purchasing 1 or 100, there may be greater savings beyond the advertised price.
Netgear GS524UP-100NAS 24-Port PoE++ Compliant Gigabit Unmanaged Ne...
Integrate the Netgear GS524UP 24-Port PoE++ Compliant Gigabit Unmanaged Network Switch into your network to quickly expand your capacity for demanding power devices. Featuring 24 Gigabit speed Ethernet ports, 16 of which provide 60W PoE++ power output while the other eight support 30W, you can operate devices such as advanced IP cameras, high-bandwidth access points, and VoIP phones. Simply connect your devices to this unmanaged switch and Netgear's auto-balance and allocation technology will automatically detect each device's needs and distribute the 480W power budget accordingly.
The GS524UP ensures smooth data transfers with a 48 Gb/s non-blocking switching capacity and 1.4 Mpps forwarding rate. Its metal casing quickly dissipates heat, allowing the switch to operate efficiently and silently while resting on a desktop or mounted in a rack with the included hardware.
Features
- 8 x Gigabit Ethernet PoE+ Ports (30W)
- 16 x Gigabit Ethernet PoE++ Ports (60W)
- 48 Gb/s Switching Capacity
- 1.4 Mpps Forwarding Rate
- 480W Power Budget
- Desktop or Rack Mountable
- Metal Housing
- Silent Operation
- Plug & Play
Specs
Netgear GS524UP-100NAS Specs
| Wi-Fi | None |
| Inputs/Outputs | 8 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE+ 16 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE (Type 3) |
| Supported Protocols | Auto-MDIX/MDI |
| Queuing | Weighted Round Robin (WRR) |
| Jumbo Frames Support | 9216 Bytes |
| MAC Address Table Size | 8K |
| Supported IEEE Standards | 802.11ax, 802.1p, 802.3, 802.3ab, 802.3at, 802.3az, 802.3bt, 802.3i, 802.3u |
| Latency | 12 µs |
| Forwarding Rate | 1.4 Mpps |
| Switching Bandwidth | 48 Gb/s (Non-Blocking) |
| Packet Buffer | 192 Kb |
| Power Draw | 24.4 W (Standby) 578.8 W (Max) |
| Current | 4 to 8 A |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| PoE Power Budget | 480 W |
| PoE per Port | 60 W |
| Power Supply Type | Internal |
| Operating Temperature | 32 to 122°F / 0 to 50°C |
| Operating Humidity | 10 to 90% (Non-Condensing) |
| Storage Temperature | -4 to 158°F / -20 to 70°C |
| Storage Humidity | 10 to 95% (Non-Condensing) |
| Operating Altitude | 9842' / 3000 m |
| Storage Altitude | 9842' / 3000 m |
| Noise Level | 35.0 dB (Active) |
| Certifications | UL62368-1, FCC47 CFR Part15B (Class A), ICES--003 Class A, EN55024/55032/55035 (Class A), VCCI, Kcc, CBIEC 60950-1, CBIEC 62368-1 Ed-3, BSMICNS14336-1, BSMICNS13438 *as per Manufacturer |
| Cooling System | Fan |
| Mean Time Between Failures (MTBF) | 809,853 Hours |
| Material of Construction | Metal |
| Indicator Lights | Fan, Link/Activity, PoE, Speed |
| Dimensions | 15.4 x 8.7 x 1.7" / 390 x 220 x 43 mm |
| Weight | 6.83 lb / 3.1 kg |
| Package Weight | 8.675 lb |
| Box Dimensions (LxWxH) | 19.1 x 12.9 x 3.8" |
