Allen & Heath AH-GR4 Rack Mount Zone Mixer

Authorized Dealer

Shipping calculated at checkout.

Allen & Heath | SKU: AH-GR4

Shipping Availability*

Free Ground Shipping on Most Orders Over $250.00

Looking for the best price or just need expert advise?
Give us a call at 1-888-230-3661 or LiveChat below.
Purchasing 1 or 100, there may be greater savings beyond the advertised price.

The GR4 from Allen & Heath is a single rackmount or desktop audio mixer that provides comprehensive control of paging and background music in restaurants, bars, stores, and other retail/leisure environments. The mixer features four mic inputs on the rear panel via Phoenix connectors with an option to select Mic 1 from an XLR input on the front panel. Additionally, there are four pairs of stereo RCA connectors for audio playback devices. The two zone outputs are offered in stereo on Phoenix connectors, but may be changed to mono via internal jumpers. An additional two mono zone outputs (3 & 4) are available with mix output being selectable from internal jumpers. The optional PL-14 remote control provides a rotary volume control with four selectable source switches and connects via standard Cat5e cabling. The GR4 ships with a power cord, blanking bung covers, a set of rack ears, four countersunk Pozi screws, and 14 Phoenix connectors.

Features

Four Mic Inputs, Four Stereo Inputs
1/8" Stereo Aux Input
Four Zone Outputs
Individual Control of Mix to Zone 1 & 2
Gain and 2-Band EQ for Mic Inputs
2-Band EQ for Zone Outputs 1 & 2
Primary and Secondary Mic Modes
Emergency Mic Mode & Juke Box Mode
Includes Rack Ears and Mounting Hardware
Includes 14 Phoenix Connectors

Specs

Microphone Inputs	Mic Input Sensitivity (Gain = Min): 0 dBu Mic Input Sensitivity (Gain = Max): -50 dBu Mic Level control (Max): +5 dB Mic Level control (Min): -80 dB Mic HPF -3 dB: 150 Hz Mic EQ LF: ±15 dB fc = 80 Hz Mic EQ HF: ±15 dB fc = 8 kHz Mic Frequency Response 20 Hz – 20 kHz: ±1 dB Mic THD+n @ 0 dBu in 1 kHz: 0.004% 22 Hz - 22 kHz Mic THD+n @ -30 dBu in 30 dB gain 1 kHz: 0.005% 22 Hz - 22 kHz Mic Hi Level warning LED (Unity gain): +18 dBu Clip level (Unity gain): +21 dBu
Stereo Inputs	ST Input Sensitivity (Gain link OFF): 0 dBu ST Input Sensitivity (Gain Link ON): -10 dBu ST Level control (Max): +6 dB ST Level control (Min): -76 dB ST Frequency response 20 Hz – 20 kHz: ±0.5 dB ST THD+n @ -10 dBu in 1 kHz: 0.015% 22 Hz - 22 kHz ST THD+n @ 0 dBu in 1 kHz: 0.035% 22 Hz - 22 kHz Crosstalk from Unselected Channel: -75 dB @ 1 kHz
Zone Output	Main Zone Level Control (Max): 0 dB Main Zone Level Control (Min): -74 dB Main Zone Hi Lev LED (Unity Gain): +18 dBu Main Zone EQ LF: ±15 dB fc = 80 Hz Main Zone EQ HF: ±15 dB fc = 8 kHz Main Zone Clip Level (Unity gain): +21 dBu
Noise	ST Input to Main Zone Output (Unity): -90 dBu 22 Hz - 22 kHz Mic Input Routed at Min Gain as Well: -88 dBu 22 Hz - 22 kHz Mic Input Routed at Max Gain: -77 dBu 22 Hz - 22 kHz (150R source)
Power	100 - 240 VAC, 50/60 Hz, 20 W Power Consumption: 15 W (with no remote attached)
Dimensions	1.9 x 9.5 x 17.2" / 48.0 x 242.0 x 438.0 mm
Weight	7.5 lb / 3.4 kg
