JBL NCSA2120R-U-US Commercial Series 2-Channel 120W Power Amplifier
JBL NCSA2120R-U-US Commercial Series 2-Channel 120W Power Amplifier is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or just need expert advise?
Give us a call at 1-888-230-3661 or LiveChat below.
Purchasing 1 or 100, there may be greater savings beyond the advertised price.
JBL NCSA2120R-U-US Commercial Series 2-Channel 120W Power Amplifier
The CSA-2120 is a professional-grade power amplifier built for commercial and installed sound applications. The amplifier is a two-channel model providing simple analog front-end processing with a switch-mode universal power supply.
JBL CSA2120R Features
- 2x 120W at 4/8Ohms
- Plenum Rated (UL2043)
- Compact size and light weight
- Convection Cooled
- Auto-standby mode for energy savings
- Summing RCA inputs for each channel
| Number of Channels | 2 |
| Power Rating | 4 Ohms / 8 Ohms: 120 W (1 kHz, 0.5% THD) |
| Load Impedance / Voltage | 4 Ohms (Minimum) 70 / 100 V |
| Frequency Response | 20 Hz to 20 kHz ±0.5 dB (8 Ohms) |
| Input Sensitivity | 1.4 Vrms |
| Input Impedance | Block: 20 Kilohms (Balanced) RCA: 50 Kilohms |
| SNR | > 100 dB |
| THD | < 0.5% |
| Crosstalk | > 70 dB |
| DSP | Yes |
| Crossover | Yes |
| EQ | 2-Band |
| Compressor | Yes |
| Limiting | Yes |
| I/O | 1 x 2RCA TS Summed-Mono Input 2 x Block 3-Pin Input 2 x Block 5-Pin 70/100 V Output |
| Digital I/O | 2 x RJ45 (Control) |
| Phantom Power | Yes |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| AC Power Connector | 1 x IEC 15 A / NEMA 5-15 |
| Certifications | ENERGY STAR *as per Manufacturer |
| Operating Temperature | 32 to 95°F / 0 to 35°C |
| Storage Temperature | -4 to 185°F / -20 to 85°C |
| Dimensions | 8.6 x 11.9 x 1.7" / 218.5 x 303.4 x 43.3 mm |
| Weight | 8.8 lb / 4 kg |
At Creartion Networks, we do everything we can to create an excellent customer experience. This includes fast shipping and easy returns.
- Most in-stock orders placed Monday-Friday ship within 24-48 hours. General restrictions apply; please see our full shipping policy here.
- We offer a 30-day return policy from the delivery date on many products. Product restrictions apply. Restocking fees for the return of open-box items. Please see our full return policy here for more information.
