RGB Spectrum D2004 – Zio 4K Video-over-IP Decoder

Product Overview

The RGB Spectrum D2004 is a Zio AV-over-IP decoder that receives HD and 4K streams over an IP network and drives a display, making it a strong fit for video walls, control rooms, and distributed digital signage. This H.264/H.265 video over IP decoder attaches to a standard 1 Gigabit Ethernet switch and feeds a connected display with content from any compatible Zio encoder. With Power over Ethernet support and a compact half-rack footprint, it streamlines installation in commercial AV systems that replace dedicated matrix switching with IP distribution. Integrators specifying scalable AV-over-IP endpoints will find the D2004 a flexible 4K decoder for enterprise, government, and security deployments.

Product Description

The D2004 is the decode endpoint in RGB Spectrum's Zio AV-over-IP platform, a family of encoders and decoders that distribute video, audio, and control over commodity IP networking instead of dedicated switchers. Zio endpoints attach to a 1 Gigabit Ethernet switch, with encoders accepting computer and video sources up to 4K and decoders such as the D2004 on the far side feeding displays or a video wall. The decoder supports both H.264 and H.265 compression and is designed to work with compatible Zio encoders like the S2004 4K encoder and other H.264/H.265 compliant devices.

Zio's peer-to-peer architecture avoids a single point of failure and scales across rooms, buildings, campuses, or cities as endpoints are added. The platform suits a local building LAN as well as lower-bandwidth links to remote sites, and it can bridge traditional baseband AV through RGB Spectrum's Linx matrix switchers so analog and digital sources coexist with IP traffic. A browser-based HTML5 control interface provides live stream thumbnails and lets operators manage endpoints from a PC, tablet, or phone. To build out a full system, browse our video processing and distribution collection or the complete RGB Spectrum line.

Key Features

• HD and 4K Decoding — Drives displays at up to 4K 4096 x 2160, so high-resolution streams reach the screen without external scaling.
• H.264 and H.265 Support — Decodes both industry-standard compression formats for compatibility with a wide range of Zio and third-party encoders.
• Power over Ethernet — PoE+ support delivers power and data over one cable to simplify display-side installation.
• Peer-to-Peer Scalability — Adds to a standard 1 Gigabit switch with no central matrix, growing from a single display to an entire campus.
• USB and Serial Control — Includes a USB-3 port and RS-232 serial control alongside network management.
• Browser-Based Control — An HTML5 interface manages streams and endpoints from Windows, macOS, iOS, and Android devices.
• Flexible Audio Support — Outputs digital embedded HDMI audio or analog mono with the decoded video.

Typical Applications

• Control rooms and command centers — Feeds operator displays and shared video walls with live IP streams from across the facility.
• Conference rooms and boardrooms — Drives meeting-room displays with sources distributed over the building network.
• Government and security spaces — Supports scalable display distribution for facilities standardized on IP infrastructure.
• Training rooms and multi-purpose rooms — Delivers shared content to multiple displays without point-to-point cabling.
• Commercial digital signage — Receives source streams to drive displays distributed across rooms or buildings.

Technical Specifications

Source: RGB Spectrum.

Frequently Asked Questions

What encoders is the D2004 compatible with?
It is designed to work with compatible Zio encoders such as the S2004, and with other H.264/H.265 compliant encode endpoints on the same network.

How is the decoder installed?
The unit has a compact 1" x 8" x 4" half-rack footprint, mounts near the display, and connects to a standard 1 Gigabit Ethernet switch; PoE+ lets a single cable carry both power and data.

How does it integrate with an existing AV system?
It attaches to a standard IP network and can bridge to traditional baseband AV through RGB Spectrum's Linx matrix switchers, with browser-based HTML5 control for stream and endpoint management.

Does it support 4K?
Yes. The D2004 decodes streams up to 3840 x 2160 @ 30 Hz and drives displays up to 4096 x 2160 @ 24 Hz.

What is the warranty and how do I get support?
The D2004 carries a 1-year warranty. For application help, quotes, or support, contact Creation Networks at 888-230-3661 or our contact page.
