Barco R9408986-B UDX-W32 32,000-Lumen WUXGA Laser DLP Projector (No Lens)

Barco SKU: R9408986-B
No reviews
Price:
$108,300.00

Description

The UDX range delivers stunning experiences and savings on installation and shipping time, reducing costs significantly. The most compact, high-brightness laser projectors with integrated cooling on the market, the UDX projectors bring reliable and razor-sharp images to every type of event and venue.

The UDX-W32 features WUXGA resolution and 32,000 lumens light output to ensure flawless shows with accurate colors at all times. The Constant Light Output (CLO) functionality also guarantees peace of mind by providing constant brightness and color over time. The UDX platform offers the widest color spectrum in the industry. Without compromising on brightness, the UDX color quality matches the renowned Xenon quality and outperforms the Rec. 709 color space.

Cut costs with laser projection

Thanks to their laser phosphor light source, lamp-related costs and maintenance as well as image flicker, belong to the past. The UDX series delivers a long lifetime and high reliability to ensure minimum downtime. The UDX's compact and rugged design allows you to reduce shipping and labor costs. The modular components can be removed quickly to limit servicing time. You can also reuse your TLD+ lenses.

Pick your brightness and resolution

The unique FLEX² feature will allow you to tune and lock your brightness and resolution to a specific show. You'll now need less projectors to cover a wider range of brightness levels and resolutions.

Faster processing for sharper images

The Barco Pulse electronics offer an intuitive interface and flexible, user-friendly, embedded control software. Its Single Step Processing (SSP) allows for sharper images and less latency.

 

  • Stunning experiences thanks to high-brightness images
  • Savings on installation and shipping time
  • Laser phosphor light source for reduced costs
  • 24/7 operation

General specifications

Projector type
WUXGA 3-chip DLP digital projector
Technology
0.96" DMD™ x3
Resolution
1,920 x 1,200
Brightness
32,000 center lumens/ 31,000 ansi lumen / 34,000 ISO
Contrast ratio
Full field 2200:1 / Barco Dyna Black 20000:1
Brightness uniformity
95%
Aspect ratio
16:10
ScenergiX
Horizontal and vertical edge blending
Lenses
TLD+ 0.37, 0.65-0.85, 0.73:1 ; 1.2:1 ; 0.8-1.16 ; 1.25 -1.6:1 ; 1.5-2.0:1 ; 2.0-2.8:1 ; 2.8-4.5:1 ; 4.5-7.5:1 ; 7.5-11.5:1
Optical lens shift
Vertical between -100% to +130%, depending on lens
Horizontal up to +/- 40%, depending on lens
Motorized zoom and focus (with lens memory on TLD lenses)
Motorized lens shift (with position memory on all lenses)
Color correction
P7
Light source
laser phosphor with inorganic phosphor wheel
Light source lifetime
25,000 hrs
Optical dowser
Digital
Picture-by-picture
Two sources simultaneously
Sealed DLP™ core
Standard
Orientation
360°
DMX 512
Standard
WARP
Direct adjust OSD + toolset
Image processing
Embedded warp & blend
Keystone correction
Yes
Integrated web server
Yes
CLO (constant light output)
Standard
3D
Active eye wear (optional), passive circular (optional); 2 flash up to 200Hz*
Inputs
Single HDBaseT; HDMI2.0 (HDCP2.2, HDR10); DP 1.2 (HDCP 1.3); Quad 3G/12G SDI / BarcoLink ULTRA
Optional Inputs
Quad DP1.2 / Fiber SFP
Input resolutions

From NTSC up to 4K (4,096 x 2,160)

refresh rates:

24hz to 120hz 4K/4KUHD (4096 x 2160/ 3860 x 2400) to 240hz WQXGA (2560 x 1600)

Max. pixel clock
600 MHz
Software tools
Projector Toolset + Android app + iOS app
Control
XLR wired + IR, RS232, Wifi (opt), GSM (opt)
Network connection
10/100 base-T, RJ-45 connection, Wifi (optional)
Power requirements
120-160V (reduced power) / 200-240V (+/- 10%), 20A, 50-60Hz
Max. power consumption
2,900 W nom / 3,100 W max. / STBY less than 10 W
Noise level (typical at 25°C/77°F)
52dB(A)
Operational ambient temperature
0-40°C / 32°-104°F
Operational humidity
0-80% (non condens)
Dissipation BTU
Max. 9,895 BTU/h
Dimensions (WxLxH)
660 x 830 x 350 mm / 25.95 x 32.7 x 13.78 inches
Shipping Dimensions
(WxLxH) 800 x 1200 x 685 mm / 31.49 x 47.24 x 26.96 inches
Weight
92kg (202 lbs)/shipping weight from factory: 110kg (242 lbs)
Standard accessories
Power cord, wireless/XLR wired rugged remote control
Certifications
Compliant with UL60950-1 and EN60950-1 complies with FCC rules & regulations, part 15 Class A and CE EN55032 Class A, Rohs
Warranty
3 years
