Lightware HDMI-TPX-RX209AK AVX (non-switchable) HDMI 2.0 extender - 91580006

Product Overview

The Lightware HDMI-TPX-RX209AK is a dedicated HDMI 2.0 TPX extender receiver, operating as the display-end unit in a point-to-point AV extension system that transmits 4K60 4:4:4 signals over a single CATx cable. It is a non-switchable extender, meaning it is designed for fixed one-to-one source-to-display runs rather than matrix or switched applications. The TPX technology provides high-bandwidth HDMI 2.0 extension over distances suited to most commercial conference room and meeting space cable runs.

Product Description

The HDMI-TPX-RX209AK receives the TPX-encoded signal from the HDMI-TPX-TX209AK transmitter and outputs HDMI 2.0 at the connected display. The extender pair supports full 4K60 4:4:4 resolution at 18 Gbps, with HDR10 and HDCP 2.2 compliance, making it a capable link for high-resolution conference room, training room, and digital signage display installations.

The receiver integrates RS-232 and IR pass-through for display control, and the Ethernet extension channel provides a network port at the display location without additional cabling. Power over the TPX link eliminates the need for a local power supply at the receiver. The non-switchable AVX architecture — Lightware's term for the dedicated point-to-point configuration — is specifically suited to permanent, fixed installations where signal routing complexity is not required and reliability and simplicity are the primary criteria. EDID management at the receiver and LW3 protocol integration round out the feature set for commercial AV deployment.

Key Features

• HDMI 2.0 Output — Delivers 4K60 4:4:4 at 18 Gbps with HDR10 to connected displays
• HDCP 2.2 Compliant — Supports end-to-end content protection for protected source playback
• TPX Extension over CATx — Receives signal over a single Cat5e or Cat6 cable from the TX209AK transmitter
• Power over TPX Link — Eliminates local power supply requirement at the display end
• RS-232 and IR Pass-through — Passes display control commands bidirectionally over the TPX cable
• Ethernet Extension — Provides a network port at the display location via the TPX link cable
• EDID Management — Programmable EDID emulation for consistent source handshaking
• LW3 Protocol — Open IP control for integration with third-party AV control systems
• Non-Switchable (AVX) Architecture — Fixed point-to-point design for simple, reliable permanent installations

Typical Applications

• Conference rooms with a fixed source-to-display cable run requiring 4K HDMI 2.0 extension
• Training rooms and classrooms with permanent instructor display connections
• Digital signage locations where a media player connects to a remote mounted display
• Boardrooms extending HDMI from a fixed podium or table source to a wall-mounted display
• Retail environments extending content from back-room media players to floor displays
• Healthcare facilities with fixed AV display connections in patient rooms or corridors

Technical Specifications

Competitor Comparison

Frequently Asked Questions

What is the difference between the TPX extender and a standard HDBaseT extender?

Lightware's TPX technology is Lightware's proprietary implementation for extending HDMI 2.0 at full 18 Gbps over CATx cabling. Standard HDBaseT 1.0 is limited to 10.2 Gbps (equivalent to HDMI 1.4), which cannot carry 4K60 4:4:4 without chroma subsampling. The TPX link provides the full HDMI 2.0 bandwidth needed for genuine 4K60 4:4:4 content.

What does non-switchable (AVX) mean?

Non-switchable means this extender pair is a fixed point-to-point connection — one transmitter feeds one receiver, with no matrix switching capability. This makes it simpler and more cost-effective for permanent conference room, classroom, or signage installations where a single source always drives a single display.

Does the receiver need a local power supply?

No. The receiver is powered via the TPX link from the HDMI-TPX-TX209AK transmitter, so no separate power supply is required at the display location.

Does this extender support 4K HDR content?

Yes. The RX209AK supports HDR10 metadata pass-through alongside 4K60 4:4:4, making it compatible with HDR-capable displays and HDR content from Blu-ray players, streaming devices, and HDR-enabled computers.

What control system can manage the EDID settings on this receiver?

EDID configuration is accessible via the LW3 protocol over IP or RS-232, which is compatible with Crestron, AMX, Extron, Savant, and custom control systems. Lightware's Device Manager software also provides a graphical interface for EDID management.

Is a Cat6 cable required, or will Cat5e work?

Cat5e is sufficient for shorter runs and lower resolutions. For full 4K60 4:4:4 performance at maximum cable distance, Cat6 is recommended. Consult Lightware's installation guide for the specific distance-resolution table for this product.

Where can I purchase the HDMI-TPX-RX209AK?

Available from Creation Networks, an authorized Lightware reseller specializing in commercial AV extender systems, integration, and project support.
