Draper Ultimate Access XL V – 270", NTSC – 145021U

Product Overview

The Draper Ultimate Access XL V is a large-format, ceiling-recessed, tab-tensioned motorized projection screen engineered for major venues such as auditoriums, convention centers, and ballrooms. This 270" NTSC (4:3) model conceals fully behind an independently motorized ceiling closure panel when retracted, then deploys through a trap door with no visible fasteners. As a large-venue tab-tensioned projection screen available in image widths up to 22' (671 cm), it holds a large image plane flat and wrinkle-free for high-quality front projection. This unit is supplied by Creation Networks at authorized-dealer pricing with Draper's standard warranty.

Product Description

The Draper Ultimate Access XL V (Part # 145021U) is a Series V tab-tensioned electric screen built for integrators specifying a fully concealed large-format ceiling-recessed projection screen for general-session and performance spaces. This 270" NTSC 4:3 configuration is sized for large audiences, and the model scales to a maximum image width of 22' (671 cm) depending on surface. The image area is framed on all sides in black with a standard 12" (30 cm) black top drop. The case installs into a ceiling pocket and includes a trim flange for a finished look; an independently motorized ceiling closure panel opens into the case and can be finished by a contractor to match the surrounding ceiling. The tab-tensioned surface uses RF-welded tabs that resist separation and sticking, maintaining a flat image plane across the large format for critical viewing. This SKU ships with Draper's LVC-IV Low Voltage Controller, and a junction box with a 110V three-position wall switch is included for recessed wall mounting; low-voltage video interfaces and third-party controls such as Crestron and Control4 can be built into the housing for below-ceiling access. The 14-1/16" high by 11" deep case supports early installation, so the housing can be set during construction and the screen added later, while adjustable hoisting brackets, sliding top brackets, and a bottom access panel simplify lifting and long-term maintenance. This model is offered with a range of Draper OptiFlex and TecVision tab-tensioned surfaces; confirm the exact surface, gain, and viewing cone for this configuration with Creation Networks before ordering. Pair the Ultimate Access XL V with a matched unit from our commercial projectors collection and a bracket from our projector mounts and lifts collection to complete the system. Browse the full Draper projection screen lineup or the broader projection screens catalog for alternate sizes and surfaces. Contact Creation Networks at creationnetworks.net for throw-distance planning, control-system integration, and lead times.

Key Features

• Large-format image up to 22' — Scales to a 22' (671 cm) maximum image width for auditoriums, convention centers, and general-session rooms.
• Ceiling-recessed concealment — The case installs into a ceiling pocket with a trim flange, hiding the screen for a finished architectural appearance.
• Independently motorized closure panel — A separate motor opens the ceiling closure panel into the case and fully conceals the screen with no visible fasteners; it can be finished to match the ceiling.
• Tab-tensioned Series V surface — RF-welded tabs hold the large surface flat and wrinkle-free, resisting separation and sticking for accurate projection geometry.
• LVC-IV low-voltage control — Ships with Draper's LVC-IV Low Voltage Controller; a junction box and 110V 3-position switch are included for recessed wall mounting.
• Early-install case — The 14-1/16" H x 11" D housing can be set during construction and the screen added later, protecting the surface during the build.
• Serviceable design — Adjustable hoisting brackets, sliding top brackets, and a bottom access panel simplify installation and maintenance in large venues.
• UL Listed with Draper warranty — Supplied by Creation Networks as an authorized dealer with full manufacturer warranty coverage.

Typical Applications

• Auditoriums and performing arts venues
• Convention centers, ballrooms, and general-session rooms
• Large houses of worship using front projection
• All-hands and large multi-purpose rooms
• Government and command spaces requiring a concealed large-format screen

Technical Specifications

Specifications sourced from Draper, Inc. (draperinc.com). Confirm exact viewing surface, gain, viewable dimensions, and surface size limits with Creation Networks before ordering.

Frequently Asked Questions

How large can the Ultimate Access XL V go?

The model scales to a maximum image width of 22' (671 cm), depending on the selected surface, which makes it suitable for auditoriums, convention centers, and large general-session rooms. This SKU is a 270" NTSC (4:3) configuration; custom sizes are available.

How does the motorized closure panel work?

An independently motorized ceiling closure panel opens into the case when the screen deploys and closes flush with the ceiling when the screen is retracted, fully concealing the housing with no visible fasteners. A contractor can finish the panel to match the surrounding ceiling.

Is this screen tab-tensioned?

Yes. The Ultimate Access XL V is a Draper Series V screen with a tab-tensioned surface. RF-welded tabs hold the large viewing surface flat and wrinkle-free, which is important for maintaining accurate geometry across a large-format image.

Which viewing surface does this 270" model use?

The Ultimate Access XL V is available with a range of Draper OptiFlex and TecVision tab-tensioned surfaces, including ambient-light-rejecting options, each with different gain and contrast. Contact us to confirm the exact surface for this configuration and to match it to your projector and venue lighting.

Can the case be installed during construction?

Yes. The case can be set early and the screen added later, which protects the surface during the build. Adjustable hoisting brackets, sliding top brackets, and a bottom access panel simplify installation and future service in large venues.

What warranty and support are included?

The Ultimate Access XL V carries Draper's standard manufacturer warranty, supplied through Creation Networks as an authorized dealer. Contact us at creationnetworks.net for pre-sale specification help, control-system integration, and post-sale support.
