Draper Ultimate Access XL V – 27' 6", NTSC – 145023U

Product Overview

The Draper Ultimate Access XL V is a large-format, ceiling-recessed, tab-tensioned electric projection screen with a motorized closure door, built for major venues that need an expansive image fully concealed when idle. This 27' 6" (330") diagonal NTSC (4:3) configuration sits near the model's 22' maximum image width, making it suited to convention centers, ballrooms, and large auditoriums. A motorized trap door and independently motorized ceiling closure panel hide the screen behind a clean ceiling line, while tab-tensioning with RF-welded tabs holds the large surface flat. All units ship through Creation Networks at authorized-dealer pricing with Draper's standard warranty.

Product Description

The Draper Ultimate Access XL V 27' 6" large-format projection screen (Part # 145023U) is specified for large rooms where a tab-tensioned image, expansive width, and fully finished ceiling all matter. The case includes a motorized trap door for smooth screen descent and an independently motorized ceiling closure panel that opens into the case; a contractor can finish the panel to match the surrounding ceiling so nothing is visible when the screen is retracted. As a Series V tab-tensioned projection screen, the surface is held flat by side tensioning tabs with RF-welded seals that prevent separation and stickiness, supporting superior image quality at large sizes. The image area is fully framed in black with a standard 12" (30 cm) black drop at the top, and a bottom access panel simplifies maintenance. This unit ships with an LVC-IV low-voltage controller, and the model includes a junction box and 110V three-position wall switch for recessed wall mounting; low-voltage or video-interface controls can be built into the housing for below-ceiling access. Installing the case early during construction protects the screen and lets it be added later. The Ultimate Access XL V supports image widths up to 22' (671 cm) and accepts Series V surfaces including OptiFlex matt white and grey plus premium TecVision options; contact us to confirm the surface for your part number. Pair it with a compatible unit from our commercial projectors collection and a bracket or lift from our projector mounts and lifts collection to complete the system. Browse the full Draper projection screen lineup for alternate sizes and surfaces, or the wider projection screens range. Contact Creation Networks at creationnetworks.net for throw-distance planning, rigging guidance, and lead times.

Key Features

• Large-format sizing to 22' — Supports image widths up to 22' (671 cm) for convention centers, ballrooms, and large auditoriums.
• Motorized closure door — A motorized trap door and independently motorized ceiling closure panel fully conceal the screen and can be finished to match the ceiling.
• Tab-tensioned Series V surface — Side tensioning tabs hold the large viewing surface flat and wave-free for superior image quality.
• RF-welded tabs — The welded tabs create a durable seal that eliminates separation and stickiness over the screen's life.
• LVC-IV low-voltage controller — Enables low-voltage integration with commercial AV control systems for the screen and closure door.
• Included junction box and wall switch — A junction box and 110V three-position wall switch are provided for recessed wall mounting.
• Black-framed image with top drop — The image area is fully framed in black with a standard 12" (30 cm) black drop at the top of the viewing area.
• Install-early case — The case can be mounted during construction and the screen added later to protect a large, high-value assembly.
• Draper warranty through an authorized dealer — Supplied by Creation Networks with full manufacturer warranty coverage.

Typical Applications

• Convention centers and hotel ballrooms requiring a very large concealed image
• Large auditoriums and performance venues with front projection
• Multi-purpose performance spaces needing expansive width
• Corporate all-hands rooms and large commercial meeting spaces
• Houses of worship using a large tab-tensioned front-projection screen

Technical Specifications

Specifications sourced from Draper, Inc. (draperinc.com). Viewing surface, gain, and exact viewable dimensions for this custom size are not shown here; confirm the surface, ceiling-pocket requirements, and electrical requirements with Creation Networks before ordering.

Frequently Asked Questions

How large is this screen?

This configuration is a 27' 6" (330") diagonal NTSC (4:3) screen, near the model's maximum image width of 22' (671 cm). The Ultimate Access XL V is a large-format model intended for major venues; confirm the exact viewable dimensions and ceiling-pocket size with Creation Networks.

What does the motorized closure door do?

The case includes a motorized trap door and an independently motorized ceiling closure panel that opens into the case. When the screen retracts, the panel closes to conceal it, and a contractor can finish the panel to match the surrounding ceiling.

Is the screen tab-tensioned?

Yes. It is a Series V tab-tensioned screen. Side tensioning tabs with RF-welded seals hold the large surface flat and wave-free, and the RF-welded tabs resist separation and stickiness.

How does it integrate with an AV control system?

This unit ships with an LVC-IV low-voltage controller for integration with commercial control systems such as Crestron or Control4, and the model includes a junction box and 110V three-position wall switch for recessed wall mounting.

Which viewing surface does this configuration use?

The Ultimate Access XL V is offered with Series V surfaces including OptiFlex Matt White XT1000VB and Grey XH600V plus premium TecVision options. Contact Creation Networks and we will confirm the exact surface for this part number before you order.

What projectors and mounts are compatible?

It works with commercial front projectors matched to its large 4:3 format and the venue's throw distance. Browse our commercial projectors and projector mounts and lifts, or contact us for a throw-distance calculation for the venue.

What warranty and support are included?

The Ultimate Access XL V carries Draper's standard 5-year manufacturer warranty, supplied through Creation Networks as an authorized dealer. Contact us at creationnetworks.net for pre-sale specification help and post-sale support.
