Draper Ultimate Access V – 113", 16:10 – 143027Q

Product Overview

The Draper Ultimate Access V is a ceiling-recessed, tab-tensioned electric projection screen with a motorized closure door, built for permanent commercial AV installations that need a fully concealed screen. This 113" diagonal 16:10 model deploys a flat, tab-tensioned image through a motorized trap door, then closes behind a ceiling panel for a clean ceiling line when idle. As a ceiling-recessed tab-tensioned projection screen, it suits mid-sized boardrooms, training rooms, and university spaces where a finished, fastener-free look matters. All units ship through Creation Networks at authorized-dealer pricing with Draper's 5-year warranty.

Product Description

The Draper Ultimate Access V ceiling-recessed projection screen is engineered for integrators who need the screen and its case completely hidden when not in use. The case installs during construction using quick-connect wiring, so the tab-tensioned screen can be added later to avoid job-site damage. Its steel case measures 9-7/8" high by 8" deep (25 cm x 20 cm) with a trim flange, and a motorized closure door drops open for deployment and seals shut afterward; the ceiling closure panel can be finished by a contractor to match the surrounding ceiling for a seamless-looking install. The tab-tensioned surface holds the image flat across the full width, and Draper's RF-welded tabs create a durable seal that eliminates stickiness and tab separation. The image area is fully framed in black with a standard 12" (30 cm) black drop at the top for correct projector alignment. Maximum image width for this model is 12' (366 cm); at 113" 16:10, this is a standard-size configuration rather than a large-format screen. A detachable bottom access panel — which can also hang from a 'T' bracket — simplifies service, and a low-voltage video interface or controls can be integrated for below-ceiling access. This unit ships with Draper's quiet motor for reduced operating noise in boardrooms and training rooms. Pair it with a compatible unit from our commercial projectors collection and a bracket from our projector mounts and lifts collection to complete the system. Browse the full Draper projection screen lineup, or the wider projection screens range. Contact Creation Networks at creationnetworks.net for configuration support, throw-distance planning, and lead times.

Key Features

• Ceiling-recessed with motorized closure door — A motorized trap door deploys the screen and seals shut, fully concealing the screen and case in the ceiling when not in use.
• Tab-tensioned viewing surface — Holds the image flat across the full width for a wrinkle-free picture in permanent installations.
• RF-welded tabs — Create a durable seal that eliminates stickiness and tab separation over the life of the screen.
• Fastener-free finished look — The ceiling closure panel can be finished by a contractor to match the ceiling for a clean, no-visible-fastener appearance.
• Quiet motor — This configuration uses Draper's quiet motor to reduce operating noise during deployment.
• Quick-connect wiring — Allows the case to be installed during construction and the screen added later to prevent job-site damage.
• Detachable bottom access panel — Removable or hangs on a 'T' bracket for straightforward service and maintenance.
• Standard 12" black drop — The image area is fully framed in black with a 12" (30 cm) top drop for correct projector alignment.
• Draper 5-year warranty through an authorized dealer — Supplied by Creation Networks with full manufacturer warranty coverage.

Typical Applications

• Mid-sized boardrooms requiring a fully concealed ceiling-recessed screen
• Training rooms and conference rooms with a finished ceiling aesthetic
• University classrooms and multi-purpose rooms
• Corporate meeting spaces where quiet operation matters
• Houses of worship using front projection with a concealed screen

Technical Specifications

Specifications sourced from Draper, Inc. (draperinc.com). Confirm exact viewable dimensions, surface selection, and surface size limits with Creation Networks before ordering.

Frequently Asked Questions

How does the Ultimate Access V conceal the screen when not in use?

A motorized closure door (trap door) opens for screen deployment and seals shut afterward, hiding both the screen and its case in the ceiling. The ceiling closure panel can be finished by a contractor to match the surrounding ceiling for a fully concealed appearance.

Is this 113" screen a large-format model?

No. The Ultimate Access V has a maximum image width of 12' (366 cm), and this 113" 16:10 unit is a standard-size configuration for mid-sized rooms. For large-format ceiling-recessed screens, see the Ultimate Access XL V.

What does the "Q" in SKU 143027Q indicate?

The Q suffix indicates Draper's quiet motor, which reduces operating noise during deployment. Low-voltage (LVC-IV) and 220V motor options are also available on this model.

Can the case be installed before the finished ceiling is complete?

Yes. Quick-connect wiring allows the case to be installed during construction, with the tab-tensioned screen added later to avoid job-site damage. This is a common workflow for new-construction AV projects.

What projectors and mounts are compatible with this screen?

Use a commercial front projector matched to the 113" 16:10 format and the room's throw distance. Browse our commercial projectors and projector mounts and lifts, or contact us for a throw-distance calculation.

What warranty and support are included?

The Ultimate Access V carries Draper's 5-year manufacturer warranty, supplied through Creation Networks as an authorized dealer. Contact us at creationnetworks.net for pre-sale specification help and post-sale support.
