Draper Premier XL – 220", HDTV – 101391CBU
Product Overview
The Draper Premier XL is a large-format motorized projection screen designed for large venues, auditoriums, and all-hands spaces where standard screen sizes are insufficient. Built on the proven Premier platform with a heavier-duty motor and reinforced housing, the Premier XL handles screen sizes up to 30 feet diagonal while maintaining the flat, tensioned surface commercial AV installations require. It is available with optional LVC-IV low-voltage controller for integration with AV control systems.
Product Description
The Draper Premier XL, 220", HDTV, CineFlex CH1200V, 110 V, with LVC-IV Low Voltage Controller (Part # 101391CBU) is available from Creation Networks, a commercial AV dealer specializing in projection screens, display systems, and AV integration products for commercial deployments. This unit ships factory-direct and is covered by Draper's standard commercial warranty.
Key configuration details: Premier XL, 220", HDTV, CineFlex CH1200V, 110 V, with LVC-IV Low Voltage Controller. Shipping weight: 439.0 lbs. All pricing shown is 2026 MAP pricing.
Key Features
- Heavy-Duty Motorized Drive — Reinforced motor system handles larger screen weights and provides reliable operation in permanent large-venue installations.
- Tab-Tensioning System — Mechanical side tensioners maintain surface flatness across the full width, critical for large projection surfaces.
- Commercial-Grade Extruded Aluminum Housing — Designed for surface or recessed installation in auditoriums and large meeting spaces.
- Multiple Projection Surfaces — Compatible with Matt White XT1000VB, CineFlex CH1200V, and TecVision high-gain surfaces.
- LVC-IV Low Voltage Controller Option — Enables 3-wire connection to building automation or AV control systems such as Crestron, AMX, or QSC.
- Multiple Formats Available — Offered in HDTV (16:9), Video (16:10), NTSC (4:3), and square (AV) formats.
- Made in USA — Manufactured at Draper's facility in Spiceland, Indiana.
Typical Applications
- Auditorium
- All-Hands Room
- Boardroom
- Conference Room
- House Of Worship
- Government Space
Technical Specifications
| Specification | Value |
|---|---|
| Size (Diagonal) | 220" |
| Aspect Ratio / Format | HDTV |
| Projection Surface | CineFlex CH1200V |
| Image Area | 108" x 192" |
| Voltage | 110 V |
| Shipping Weight | 439.0 lbs |
| Control Options | LVC-IV Low Voltage Controller |
| SKU / Part Number | 101391CBU |
| Country of Origin | USA |
| Vendor | Draper |
| MAP Price | $8446.00 |
| MSRP | $10558.00 |
Frequently Asked Questions
Q: Is the Draper Premier XL compatible with standard AV control systems?
Yes. Models with the LVC-IV option include a 3-wire low-voltage input compatible with Crestron, AMX, Extron, QSC, and similar commercial AV control systems. Standard models operate via a 3-button wall switch (up, stop, down) and include IR control capability.
Q: What projection surfaces are available for this model?
This specific unit uses CineFlex CH1200V surface material. The Premier XL is available in multiple surface options including Matt White XT1000VB (or XT1000E for E-series), CineFlex CH1200V, Contrast Grey XH800E, and various TecVision ambient light rejecting surfaces. Contact Creation Networks to confirm surface availability for a specific size.
Q: What voltage does this unit require?
This unit operates on 110 V. Refer to the product label and local electrical code for installation wiring requirements.
Q: What is the warranty on this Draper product?
Draper projection screens are covered by a limited manufacturer's warranty. Contact Creation Networks or Draper directly at draperinc.com for current warranty terms and conditions.
Q: Can this screen be integrated into a larger AV system?
Yes. The LVC-IV option enables low-voltage 3-wire integration with commercial AV control systems. Creation Networks can assist with system design and configuration.
