Draper Premier XL – 208 3/8", 21:9 Ultrawide – 101821U

Product Overview

The Draper Premier XL is a large-format, tab-tensioned motorized projection screen configured here for ultrawide 21:9 front-projection installations. This 208 3/8" diagonal model pairs the Matt White XT1000VB surface with a factory LVC-IV low-voltage controller, making it a strong fit as a 21:9 ultrawide motorized screen for auditoriums, all-hands rooms, and large commercial meeting spaces. As a large-format tab-tensioned electric screen, it delivers a flat, wrinkle-free image across a full 180° viewing cone. All units ship through Creation Networks at authorized-dealer pricing with Draper's manufacturer warranty.

Product Description

The Draper Premier XL 208 3/8" ultrawide projection screen (Part # 101821U) is an electric, ceiling- or wall-mounted screen built for integrators specifying a 21:9 ultrawide front-projection screen in large venues. The tab-tensioning system uses side tab-guide cables and a weighted bottom dowel to hold the surface flat, which is critical for image geometry on a wide 21:9 surface, and the RF-welded tabs are warranted against separation for five years. The Matt White XT1000VB surface is a matt white diffusing surface with 1.0 gain that reflects a uniformly bright image across a full 180° viewing cone with accurate color balance, making it suited to front projection where ambient light can be reasonably controlled. This unit is supplied with the LVC-IV low-voltage controller for integration with commercial AV control and building-automation systems. The fabricated extruded aluminum case has a curved front and black finish and measures 6-3/4" high by 6-3/4" deep for a compact profile above the image, with a standard 12" black top drop and optional wall or ceiling mounting brackets. Pair it with a compatible unit from our commercial projectors collection and a bracket from our projector mounts and lifts collection to complete the system. Browse the full Draper projection screen lineup for alternate sizes, surfaces, and formats. Contact Creation Networks at creationnetworks.net for configuration support, throw-distance planning, and lead times.

Key Features

• 21:9 ultrawide format — A wide 21:9 image area suited to panoramic content and data-dense presentations in large rooms.
• Matt White XT1000VB surface — Delivers 1.0 gain and a full 180° viewing cone with accurate color for wide seating layouts in controlled-light rooms.
• Tab-tensioned viewing surface — Side tab-guide cables and a weighted bottom dowel keep the surface flat for consistent image geometry across the full width.
• Factory LVC-IV low-voltage controller — Provides a low-voltage control interface for integration with commercial AV control and automation systems.
• Large-format sizing — Supports large commercial image sizes up to a 16' (488 cm) maximum image width for large venues.
• Extruded aluminum case — A fabricated aluminum case with curved front and black finish measures 6-3/4" high by 6-3/4" deep for a compact profile.
• RF-welded tabs — Radio-frequency welded tabs form a durable seal and are warranted against separation for five years.
• Draper warranty through an authorized dealer — Supplied by Creation Networks with full manufacturer warranty coverage.

Typical Applications

• Auditoriums requiring a large-format panoramic front-projection image
• All-hands rooms and large commercial meeting spaces
• Houses of worship using front projection in large sanctuaries
• Government spaces and multi-purpose rooms displaying wide-format content
• Training rooms needing a retractable ultrawide surface

Technical Specifications

Specifications sourced from Draper, Inc. (draperinc.com). Confirm exact viewable dimensions and surface size limits with Creation Networks before ordering.

Frequently Asked Questions

Is the Draper Premier XL a tab-tensioned screen?

Yes. The Premier XL is a Draper Series V tab-tensioned electric screen. Side tab-guide cables and a weighted bottom dowel maintain even tension, holding the ultrawide surface flat for consistent image geometry.

What performance does the Matt White XT1000VB surface provide?

Matt White XT1000VB is a matt white diffusing surface with 1.0 gain and a full 180° viewing cone, delivering uniform brightness and accurate color across wide seating layouts. It is recommended for front projection where ambient light can be reasonably controlled.

What is the maximum image size for this model?

The Premier XL is a large-format model with a maximum image width up to 16' (488 cm). This unit is a 208 3/8" diagonal screen in 21:9 ultrawide format. Contact Creation Networks to confirm exact viewable dimensions for your room.

What does the LVC-IV controller connect to?

This unit ships with the LVC-IV low-voltage controller, which provides a low-voltage control interface for integration with commercial AV control and building-automation systems. Ask Creation Networks about wiring and interface options for your control platform.

What projectors and mounts are compatible with the Premier XL?

It works with any commercial front projector matched to its 208 3/8" 21:9 format and your room's throw distance. Browse our commercial projectors and projector mounts and lifts, or contact us for a throw-distance calculation.

What warranty and support are included?

The Premier XL carries Draper's manufacturer warranty, including a five-year warranty against RF-welded tab separation, supplied through Creation Networks as an authorized dealer. Contact us at creationnetworks.net for pre-sale specification help and post-sale support.
