Draper Premier XL – 208 3/8", 21:9 Ultrawide – 101821Q

Product Overview

The Draper Premier XL is a wall- or ceiling-mounted, large-format tab-tensioned projection screen built for auditoriums, all-hands rooms, and large venues where standard screen sizes fall short. This 208 3/8" diagonal 21:9 Ultrawide model is configured with the Matt White XT1000VB surface and a quiet motor, delivering a 1.0-gain image with a full 180° viewing cone across wide seating layouts. As a tab-tensioned screen it uses RF-welded tabs and a side tab-guide cable system to hold a flat surface across the full width. All units ship through Creation Networks at authorized-dealer pricing with Draper's five-year warranty.

Product Description

The Draper Premier XL tab-tensioned screen is an economical large-format electric screen for integrators specifying wide-image projection in permanent installations. The fabricated extruded aluminum case measures 6-3/4" high x 6-3/4" deep with a curved front and L-shaped back/top cover in a black finish, and Draper rates the model for image widths up to 16' (488 cm). The tab-tensioned design uses RF-welded tabs, warranted against separation for five years, with a tab-guide cable on each side to maintain even lateral tension and a flat viewing surface at large sizes. This unit is configured with the OptiFlex Matt White XT1000VB surface, a matt white diffusing surface with 1.0 gain and a full 180° viewing cone that reflects a uniformly bright image with accurate color, recommended for all projector types where ambient light can be reasonably controlled. The image area is fully framed in black with a standard 12" black top drop, and this configuration includes Draper's quiet motor for lower operational noise in occupied rooms. The screen ships with a 110-120V three-position switch as standard, is wired for 110 V, and offers optional low-voltage Plug & Play or additional control options. Optional wall or ceiling mounting brackets add installation flexibility, and the screen is UL Listed. Pair it with a compatible unit from our commercial projectors and a bracket from our projector mounts and lifts collection to complete the system. Browse the full Draper projection screen lineup for alternate sizes and surfaces. Contact Creation Networks at creationnetworks.net for configuration support, throw-distance planning, and lead times.

Key Features

• Large-format tab-tensioned surface — RF-welded tabs and side tab-guide cables hold a flat viewing surface across image widths up to 16' (488 cm).
• Matt White XT1000VB surface, 1.0 gain — A matt white diffusing surface with a full 180° viewing cone for uniform brightness and accurate color across wide seating.
• Quiet motor — This configuration uses Draper's quiet motor to reduce operational noise in occupied auditoriums and meeting spaces.
• Fabricated aluminum case — A 6-3/4" x 6-3/4" extruded aluminum case with a curved front and black finish for permanent large-venue installations.
• RF-welded tabs, five-year seal warranty — The welded tabs are warranted against separation for five years for reliable long-term flatness.
• Flexible mounting — Optional wall or ceiling mounting brackets support surface installation in auditoriums and large meeting spaces.
• UL Listed — Carries UL Listing and Draper's five-year warranty, supplied by Creation Networks as an authorized dealer.

Typical Applications

• Auditoriums and large venues requiring wide-format front projection
• All-hands rooms and large commercial meeting spaces
• Houses of worship with wide-format front-of-house imaging
• Training rooms and multi-purpose rooms needing large projection surfaces
• Government and corporate spaces with large-audience presentation needs

Technical Specifications

Specifications sourced from Draper, Inc. (draperinc.com). Confirm exact viewable dimensions and surface size limits with Creation Networks before ordering.

Frequently Asked Questions

What is the maximum image width of the Premier XL?

Draper rates the Premier XL for image widths up to 16' (488 cm). This 208 3/8" 21:9 Ultrawide model falls within that range. For sizes beyond the Premier XL's maximum, contact Creation Networks about alternate large-format models.

Is the Premier XL tab-tensioned?

Yes. The Premier XL uses a tab-tensioned surface with RF-welded tabs and a side tab-guide cable system that maintains even lateral tension for a flat image at large sizes. The welded tabs are warranted against separation for five years.

Why choose the Matt White XT1000VB surface?

Matt White XT1000VB is a 1.0-gain diffusing surface with a full 180° viewing cone. It reflects a uniformly bright image with accurate color and works with all projector types where ambient light can be reasonably controlled, making it a versatile choice for large presentation venues.

What projectors and mounts are compatible with the Premier XL?

It works with commercial projectors matched to its 208 3/8" 21:9 format and your room's throw geometry. Browse our commercial projectors and projector mounts and lifts, or contact us for a throw-distance calculation.

How is the Premier XL installed and controlled?

It is a wall- or ceiling-mounted electric screen using optional mounting brackets, and ships with a 110-120V three-position switch. This unit is wired for 110 V and configured with a quiet motor. Optional low-voltage Plug & Play control is available for AV control system integration.

What warranty and support are included?

The Premier XL carries Draper's five-year warranty (USA and Canada) and is UL Listed, supplied through Creation Networks as an authorized dealer. Contact us at creationnetworks.net for pre-sale specification help and post-sale support.
