Draper Premier XL – 198", 16:10 – 101785

Product Overview

The Draper Premier XL is a large-format, tab-tensioned motorized projection screen for auditoriums, all-hands rooms, and large commercial meeting spaces. This 198" diagonal model in 16:10 format pairs the Matt White XT1000VB surface with an extruded aluminum case, making it a strong fit as a 16:10 motorized projection screen for large-venue front projection. As a large-format tab-tensioned electric screen, it delivers a flat, wrinkle-free image across a full 180° viewing cone. All units ship through Creation Networks at authorized-dealer pricing with Draper's manufacturer warranty.

Product Description

The Draper Premier XL 198" projection screen (Part # 101785) is an electric, ceiling- or wall-mounted screen built for integrators specifying a 16:10 widescreen projection screen in large rooms. The tab-tensioning system uses side tab-guide cables and a weighted bottom dowel to hold the surface flat, which is critical for image geometry across wide surfaces, and the RF-welded tabs are warranted against separation for five years. The Matt White XT1000VB surface is a matt white diffusing surface with 1.0 gain that reflects a uniformly bright image across a full 180° viewing cone with accurate color balance, making it suited to front projection where ambient light can be reasonably controlled. This unit has a 105" x 168" image area and operates on 220V, shipping with Draper's standard 110-120V three-position control switch; optional low-voltage and quiet motor controllers are available on other Premier XL configurations for tighter AV system integration. The fabricated extruded aluminum case has a curved front and black finish and measures 6-3/4" high by 6-3/4" deep for a compact profile above the image, with a standard 12" black top drop and optional wall or ceiling mounting brackets. Pair it with a compatible unit from our commercial projectors collection and a bracket from our projector mounts and lifts collection to complete the system. Browse the full Draper projection screen lineup for alternate sizes, surfaces, and formats. Contact Creation Networks at creationnetworks.net for configuration support, throw-distance planning, and lead times.

Key Features

• 16:10 widescreen format — A 16:10 image area suited to data presentation, computer-driven content, and mixed AV in commercial rooms.
• Matt White XT1000VB surface — Delivers 1.0 gain and a full 180° viewing cone with accurate color for wide seating layouts in controlled-light rooms.
• Tab-tensioned viewing surface — Side tab-guide cables and a weighted bottom dowel keep the surface flat for consistent image geometry across the full width.
• Standard three-position control — Ships with Draper's standard 110-120V three-position switch, with optional low-voltage and quiet motor controllers available on other configurations.
• Large-format sizing — Supports large commercial image sizes up to a 16' (488 cm) maximum image width for large venues.
• Extruded aluminum case — A fabricated aluminum case with curved front and black finish measures 6-3/4" high by 6-3/4" deep for a compact profile.
• RF-welded tabs — Radio-frequency welded tabs form a durable seal and are warranted against separation for five years.
• Draper warranty through an authorized dealer — Supplied by Creation Networks with full manufacturer warranty coverage.

Typical Applications

• Auditoriums requiring a large-format 16:10 front-projection image
• All-hands rooms and town-hall spaces in corporate facilities
• Houses of worship using front projection in large sanctuaries
• Government spaces and large commercial meeting rooms
• Multi-purpose rooms and training rooms needing a retractable large screen

Technical Specifications

Specifications sourced from Draper, Inc. (draperinc.com). Confirm exact viewable dimensions and surface size limits with Creation Networks before ordering.

Frequently Asked Questions

Is the Draper Premier XL a tab-tensioned screen?

Yes. The Premier XL is a Draper Series V tab-tensioned electric screen. Side tab-guide cables and a weighted bottom dowel maintain even lateral and vertical tension, holding the surface flat for consistent image geometry on large surfaces.

What performance does the Matt White XT1000VB surface provide?

Matt White XT1000VB is a matt white diffusing surface with 1.0 gain and a full 180° viewing cone, delivering uniform brightness and accurate color across wide seating layouts. It is recommended for front projection where ambient light can be reasonably controlled.

What is the image area and maximum image size?

This unit has a 105" x 168" image area in 16:10 format. The Premier XL is a large-format model with a maximum image width up to 16' (488 cm). Contact Creation Networks to confirm exact viewable dimensions for your room.

How is this base-configuration screen controlled?

The base Premier XL ships with Draper's standard 110-120V three-position control switch. Other Premier XL configurations add optional low-voltage (LVC-IV) or quiet motor controllers for closer integration with commercial AV control systems.

What projectors and mounts are compatible with the Premier XL?

It works with any commercial front projector matched to its 198" 16:10 format and your room's throw distance. Browse our commercial projectors and projector mounts and lifts, or contact us for a throw-distance calculation.

What warranty and support are included?

The Premier XL carries Draper's manufacturer warranty, including a five-year warranty against RF-welded tab separation, supplied through Creation Networks as an authorized dealer. Contact us at creationnetworks.net for pre-sale specification help and post-sale support.
