Draper Premier – 150", NTSC – 101354

Product Overview

The Draper Premier is a tab-tensioned, motorized electric projection screen for permanent commercial AV installations, and this 150" model is built in the NTSC (4:3) format for slide decks, document cameras, and legacy 4:3 presentation sources. As a 150 inch motorized projection screen, it drops from a wall- or ceiling-mounted steel case and holds a flat, wrinkle-free image through Draper's tab-tensioning system. It suits large conference rooms, training rooms, and multi-purpose rooms that still standardize on a 4:3 image. All units ship through Creation Networks at authorized-dealer pricing with Draper's standard warranty.

Product Description

The Draper Premier tab-tensioned electric projection screen is engineered for integrators specifying a dependable motorized screen with a consistently flat viewing surface. This unit is configured in the 150" NTSC (4:3) format with the Grey XH600V surface for improved contrast in rooms with some ambient light. The screen retracts into a pentagonal steel case with a black plastisol finish (white is optional) and matching endcaps with universal mounting brackets, so it can be surface-mounted to a wall or ceiling. Tab-tensioning with RF-welded tabs keeps the surface taut across its full width, and the RF-welded tabs are warranted against separation and stickiness. The image area is fully framed in black with a standard 12" (30 cm) black drop at the top of the viewing area, and an optional white aluminum ceiling trim kit is available for recessed installation. As a commercial motorized projection screen, the Premier ships standard with a 110-120V three-position control switch and supports additional control options for integration into a larger AV system. Pair it with a compatible unit from our commercial projectors collection and a bracket from our projector mounts and lifts collection to complete the deployment. Browse the full Draper projection screen lineup for alternate sizes and surfaces, or the broader projection screens collection. Contact Creation Networks at creationnetworks.net for throw-distance planning, surface selection, and lead times.

Key Features

• 150" NTSC (4:3) format — The large 4:3 diagonal suits data presentations, document cameras, and rooms standardized on legacy 4:3 sources.
• Tab-tensioned viewing surface — Side tab-tensioning holds the surface flat and wrinkle-free across the full width for accurate, distortion-free projected images.
• RF-welded tabs — The tabs are radio-frequency welded to create a durable seal that resists separation and stickiness over the life of the screen.
• Pentagonal steel case — The screen retracts into a black plastisol-finished steel case (white optional) with matching endcaps and universal mounting brackets for wall or ceiling installation.
• Grey XH600V surface — The grey viewing surface improves perceived contrast for rooms that retain some ambient light.
• Black masking border — The image area is fully framed in black with a standard 12" (30 cm) top drop to position the image and hide the roller.
• AV control ready — A 110-120V three-position switch is standard, with additional low-voltage control options available for integration with commercial AV systems.
• Draper warranty through an authorized dealer — Supplied by Creation Networks with Draper's standard 5-year limited warranty and UL-listed construction.

Typical Applications

• Large conference rooms and commercial meeting spaces with front projection
• Training rooms and multi-purpose rooms using 4:3 presentation sources
• Corporate boardrooms requiring a retractable motorized screen
• Houses of worship using motorized front-projection screens
• Government and briefing spaces needing a clean, concealed screen when retracted

Technical Specifications

Specifications sourced from Draper, Inc. (draperinc.com). Confirm exact viewable dimensions and surface size limits with Creation Networks before ordering.

Frequently Asked Questions

Is the Draper Premier a tab-tensioned screen?

Yes. The Premier uses Draper's tab-tensioning system with RF-welded tabs to hold the viewing surface flat and wrinkle-free across its full width, which is important for maintaining a distortion-free image on a large motorized screen.

What aspect ratio is this 150" model?

This unit is built in the NTSC (4:3) format, which is well suited to legacy 4:3 presentation sources, document cameras, and data slides. The Premier is also offered in HDTV (16:9), 16:10, and 21:9 formats in other configurations.

What projectors and mounts are compatible with the Premier?

The Premier works with any commercial front projector matched to its 150" 4:3 format and your room's throw distance. Browse our commercial projectors and projector mounts and lifts, or contact us for a throw-distance calculation.

How is the Premier installed?

It is a surface-mounted motorized screen. The steel case ships with matching endcaps and universal mounting brackets for wall or ceiling installation, and an optional white aluminum ceiling trim kit is available for recessed applications.

Can this screen be integrated with an AV control system?

Yes. The Premier ships standard with a 110-120V three-position control switch, and Draper offers additional low-voltage control options for integration with commercial AV control systems.

What warranty and support are included?

The Premier carries Draper's standard 5-year limited warranty and is UL Listed, supplied through Creation Networks as an authorized dealer. Contact us at creationnetworks.net for pre-sale specification help and post-sale support.
