Draper Access V – 92", HDTV – 140106FBQU

Product Overview

The Draper Access V is a ceiling-recessed, tab-tensioned electric projection screen built for commercial AV installations that need a flat tensioned image and a fully concealed screen when idle. This 92" diagonal HDTV (16:9) model is a Series V screen with a plenum-rated case, making it suitable for boardrooms, conference rooms, and training rooms tied into air-handling ceiling spaces. Tab-tensioning holds the surface flat and wrinkle-free, and a plug-in wiring system lets the case be installed early during construction. All units ship through Creation Networks at authorized-dealer pricing with Draper's standard warranty.

Product Description

The Draper Access V 92" ceiling-recessed tab-tensioned projection screen (Part # 140106FBQU) is specified by integrators who want the flat, stable image of a tensioned surface in a concealed motorized screen. As a Series V screen, the viewing surface is held flat by tensioning tabs down each side for a wrinkle-free picture, and the image area is fully framed in black with a standard 12" (30 cm) black drop at the top. The steel case installs into a ceiling pocket with a trim flange and is plenum-rated for use in air-handling spaces, and a bottom access panel detaches for maintenance without visible fasteners. Quick-connect wiring allows the case to be mounted during construction with the screen added later to prevent job-site damage, and low-voltage, video-interface, or other controls can be built into the housing for below-ceiling access. This unit ships with a quiet motor and LVC-IV low-voltage controller for low-noise operation and integration with automated AV control. The Access V accepts a wide range of Draper Series V surfaces, including OptiFlex matt white and grey options, premium TecVision performance surfaces, and acoustically transparent NanoPerf variants; contact us to confirm the surface for your configuration. Pair it with a compatible unit from our commercial projectors collection and a bracket from our projector mounts and lifts collection to complete the system. Browse the full Draper projection screen lineup for alternate sizes and surfaces, or the wider projection screens range. Contact Creation Networks at creationnetworks.net for throw-distance planning, surface selection, and lead times.

Key Features

• Tab-tensioned Series V surface — Side tensioning tabs hold the viewing surface flat for a wrinkle-free, stable image.
• Ceiling-recessed concealment — The case recesses into the ceiling with a trim flange and hides the screen completely when retracted.
• Plenum-rated case — The case is rated for installation in air-handling (plenum) ceiling spaces, easing code compliance on commercial projects.
• Black-framed image with top drop — The image area is fully framed in black with a standard 12" (30 cm) black drop at the top of the viewing area.
• Quiet motor with LVC-IV controller — The screen cycles quietly and integrates with low-voltage control wiring for automated AV systems.
• Detachable bottom access panel — The panel opens for service and maintenance without visible fasteners or removing the case from the ceiling.
• Quick-connect wiring — The case can be installed early during construction and the screen added later to prevent job-site damage.
• Wide surface compatibility — Accepts Draper Series V surfaces including OptiFlex, premium TecVision, and acoustically transparent NanoPerf options.
• Draper warranty through an authorized dealer — Supplied by Creation Networks with full manufacturer warranty coverage.

Typical Applications

• Corporate boardrooms requiring a flat tensioned image and concealed screen
• Conference rooms and commercial meeting spaces tied into plenum ceiling spaces
• Training rooms and all-hands rooms with front projection
• Higher-education classrooms and lecture spaces needing hidden projection when idle
• Multi-purpose rooms integrated with low-voltage AV control systems

Technical Specifications

Specifications sourced from Draper, Inc. (draperinc.com). Viewing surface, gain, and voltage for this configuration are not shown here; confirm the exact surface and electrical requirements with Creation Networks before ordering.

Frequently Asked Questions

Is the Access V tab-tensioned?

Yes. It is a Series V tab-tensioned screen. Tensioning tabs down each side hold the viewing surface flat for a wrinkle-free image, which is the main difference from the free-hanging Series E Access E.

Is the case plenum-rated?

Yes. The Access V case is plenum-rated for use in air-handling ceiling spaces, which helps with code compliance when the screen recesses into a return-air plenum. Confirm local requirements with your AHJ.

Which viewing surface does this configuration use?

The Access V is offered with many Series V surfaces, including OptiFlex matt white and grey, premium TecVision performance surfaces, and acoustically transparent NanoPerf options. Contact Creation Networks and we will confirm the exact surface for this part number before you order.

Can the case be installed before the screen during construction?

Yes. Quick-connect wiring lets the case be mounted and wired early, with the tensioned screen added later to prevent job-site damage during the build.

What projectors and mounts are compatible with the Access V?

It works with any commercial front projector matched to its 92" HDTV format and your room's throw distance. Browse our commercial projectors and projector mounts and lifts, or contact us for a throw-distance calculation.

Does the screen integrate with Crestron or Control4 systems?

Yes. With the LVC-IV low-voltage controller and built-in control options, the screen can be driven by third-party control systems such as Crestron or Control4 within a larger AV automation design.

What warranty and support are included?

The Access V carries Draper's standard 5-year manufacturer warranty, supplied through Creation Networks as an authorized dealer. Contact us at creationnetworks.net for pre-sale specification help and post-sale support.
