Draper Access V, 137", 16:10, Grey XH600V, 110 V - 140039FB
Product Overview
The Draper Access V (140039FB) is a motorized, ceiling-recessed projection screen for commercial AV integration. This configuration covers a 137" 16:10 image area with the Grey XH600V viewing surface. The tab-tensioning system maintains a flat, uniform image plane. The standard 3-position wall switch provides up/down/stop motor control; Quiet Motor and LVC-IV are available as factory-built options. The plenum-rated case is UL-listed for air-handling ceiling spaces.
Product Description
The Access V uses Draper’s tab-tensioning system to keep the screen surface taut. The Grey XH600V is a grey diffuse surface with 0.6 gain designed for conference rooms with ambient light. At 137" diagonal in the 16:10 format, this screen suits larger conference rooms and boardrooms where ambient light control is limited. The case-now-screen-later installation allows the housing to be set during rough-in and the screen added at finish stage.
Key Features
- Grey XH600V viewing surface — 0.6 gain grey diffuse; enhanced contrast in ambient light environments.
- 137" 16:10 format — Widescreen for larger conference rooms with ambient light.
- Tab-tensioning system — Maintains flat, uniform image plane.
- Ceiling-recessed concealed design — Screen retracts above ceiling when not in use.
- Standard 3-position motor switch — 110–120V; Quiet Motor and LVC-IV available factory-built.
- Plenum-rated case — UL-listed as “Suitable for Use in Environmental Air Space.”
Typical Applications
- Large conference room with ambient light from windows
- Corporate boardroom with limited light control
- Executive presentation suite
- University lecture hall
- Government meeting room
- Digital signage in commercial spaces
Technical Specifications
| Specification | Value |
|---|---|
| Model / Part Number | Access V (140039FB) |
| Image Format | 16:10 |
| Diagonal Image Size | 137" |
| Viewing Surface | Grey XH600V |
| Gain | 0.6 |
| Tensioning | Tab-tensioned |
| Motor Voltage | 110V |
| Included Control | 110–120V 3-position switch (standard) |
| Optional Controls | Quiet Motor (FBQ); LVC-IV (FBU); Quiet Motor + LVC-IV (FBQU) |
| Case Rating | Plenum-rated |
Frequently Asked Questions
When should I choose Grey XH600V over Matt White XT1000VB?
Choose Grey XH600V when the room has ambient light that cannot be fully controlled.
What is the difference between Access V and Access E?
The Access V uses a tab-tensioning system that keeps the screen surface taut, ensuring flat image geometry from edge to edge.
Is the case plenum-rated?
Yes. UL-listed as “Suitable for Use in Environmental Air Space.”
