Draper Access E, 222", 16:10, Matt White XT1000E, 110 V, with LVC-IV Low Voltage Controller - 139045U

Product Overview

The Draper Access E (139045U) is a motorized, ceiling-recessed projection screen for commercial AV integration. This configuration covers a 222" 16:10 image area with the Matt White XT1000E viewing surface — a 1.0-gain matte white material with a 180° viewing angle, suited for controlled-ambient rooms with broad audience seating. The LVC-IV Low Voltage Controller enables direct integration with Crestron, Control4, Extron, AMX, and other commercial AV platforms. The plenum-rated case is UL-listed for air-handling ceiling spaces.

Product Description

The Access E uses the same case-now-screen-later installation concept as Draper's ceiling-recessed screen line — the housing installs during rough-in and the screen drops in at finish stage via preset latching brackets and pin connectors. The 222" diagonal is one of the largest standard configurations in the Access E lineup, suited for large lecture halls, auditoriums, and multi-purpose spaces where widescreen laptop-format content is the primary source.

The Matt White XT1000E delivers 1.0 gain with a 180° viewing angle — neutral brightness output with wide horizontal viewing coverage, suited for rooms with controlled ambient light and broad seating configurations. The 16:10 format matches the native resolution of laptop and widescreen desktop displays, eliminating letterboxing from laptop-sourced presentations. The LVC-IV controller enables low-voltage integration with commercial AV control systems without requiring 110V switching at the control device.

The plenum-rated case meets UL requirements for air-handling spaces. Custom sizes within the maximum image width are available from Creation Networks.

Key Features

• Ceiling-recessed concealed design — Screen retracts above the ceiling tile when not in use.
• Case now, screen later installation — Housing installs during rough-in; screen drops in later via preset latching brackets and pin connectors.
• Matt White XT1000E viewing surface — 1.0 gain, 180° viewing angle; neutral brightness for controlled-ambient rooms.
• 222" 16:10 format — Large-format widescreen matching laptop and desktop display resolutions.
• LVC-IV Low Voltage Controller — Direct integration with Crestron, Extron, AMX, Control4, and other commercial AV control platforms.
• Motor-in-roller design — Motorized deployment and retraction.
• Plenum-rated case — UL-listed as “Suitable for Use in Environmental Air Space.”
• Bottom access panel — Service access without removing the case.
• Quick-connect wiring — Pin-based connections support case rough-in before screen installation.

Typical Applications

• Large university lecture hall with laptop-based presentations
• Corporate auditorium with widescreen content and AV control system
• Government training facility with 16:10 format AV systems
• Multi-purpose room with laptop-sourced widescreen presentations
• Commercial conference center with AV control integration
• Institutional large-format presentation room

Technical Specifications

Frequently Asked Questions

What is the difference between the Access E and Access V?
The Access E features the Matt White XT1000E surface (1.0 gain, 180°) and includes Quiet Motor and LVC-IV as separate factory-installed options. The Access V features CineFlex surfaces (XT700V, CH1200V, Grey XH600V, NanoPerf) suited for specific ambient light conditions. Contact Creation Networks to determine the right model for your installation.

What AV control systems does the LVC-IV support?
Crestron, Extron, AMX, Control4, and most commercial platforms with low-voltage relay or RS-232 outputs. No proprietary gateway required.

Can the case be installed before the screen arrives?
Yes. The case installs during rough-in; the screen drops in later via preset latching brackets and pin connectors.

Is the case plenum-rated?
Yes. UL-listed as “Suitable for Use in Environmental Air Space.”
