Draper Access E – 133", HDTV – 139129Q

Product Overview

The Draper Access E is a ceiling-recessed, electric projection screen built for commercial AV installations that need the screen concealed above a finished ceiling when idle. This 133" diagonal HDTV (16:9) model pairs a quiet 220V motor with the unity-gain Matt White XT1000E surface, making it a strong fit for larger conference rooms, training rooms, and lecture spaces. As a free-hanging Series E screen, it holds a flat image through the weight of the viewing surface and bottom dowel rather than tab-tensioning. All units ship through Creation Networks at authorized-dealer pricing with Draper's standard warranty.

Product Description

The Draper Access E 133" ceiling-recessed projection screen (Part # 139129Q) is specified by integrators who need a concealed, motorized front-projection surface in permanent commercial rooms. The steel case installs into a ceiling pocket and includes a trim flange for a finished architectural line, while a detachable bottom access panel door opens for later service and motor or fabric replacement. Quick-connect wiring lets the case be mounted during construction and the screen added later, supporting phased AV fit-outs, and sliding brackets on top of the case allow mounting points to be shifted around building structure. This unit uses the Matt White XT1000E surface, a smooth, non-embossed unity-gain material that diffuses light evenly for a 1.0-gain image across a 180° viewing cone with accurate color rendition; it is GREENGUARD Gold certified for indoor air quality. The quiet 220V motor keeps operating noise low in occupied meeting rooms, and adequate ambient-light control is recommended for best contrast. As a free-hanging Series E screen, the Access E is non-tensioned and relies on the bottom dowel and surface weight to stay flat. Pair it with a compatible unit from our commercial projectors collection and a bracket from our projector mounts and lifts collection to complete the system. Browse the full Draper projection screen lineup for alternate sizes and surfaces, or the wider projection screens range. Contact Creation Networks at creationnetworks.net for throw-distance planning, configuration support, and lead times.

Key Features

• Ceiling-recessed concealment — The case installs into a ceiling pocket with a trim flange so the screen is hidden from view when retracted.
• Unity-gain Matt White XT1000E surface — The smooth, non-embossed surface delivers a 1.0-gain image with accurate color and even light diffusion.
• 180° viewing cone — The panoramic viewing cone with typical contrast keeps brightness consistent across wide seating layouts.
• GREENGUARD Gold certified surface — The viewing surface meets GREENGUARD Gold criteria for low chemical emissions in occupied indoor spaces.
• Quiet 220V motor — The screen cycles with reduced operating noise, suiting conference rooms and lecture spaces in active use.
• Free-hanging Series E design — The viewing surface and bottom dowel hold the image flat without tab-tensioning for straightforward operation.
• Detachable bottom access panel — The panel door opens for service and maintenance without removing the full case from the ceiling.
• Quick-connect wiring — The case can be installed early during construction and the screen added later to support phased AV projects.
• Draper warranty through an authorized dealer — Supplied by Creation Networks with full manufacturer warranty coverage.

Typical Applications

• Larger conference rooms and commercial meeting spaces needing a concealed motorized screen
• Corporate training rooms and all-hands rooms with front projection
• Higher-education classrooms and lecture halls requiring hidden projection when idle
• Boardrooms where a clean architectural ceiling line is a priority
• Multi-purpose rooms cycling the screen throughout the day with a quiet motor

Technical Specifications

Specifications sourced from Draper, Inc. (draperinc.com). Confirm exact viewable dimensions and surface size limits with Creation Networks before ordering.

Frequently Asked Questions

Is the Draper Access E tab-tensioned?

No. The Access E is a free-hanging Series E screen. It is non-tensioned and maintains a flat image through the weight of the viewing surface and the bottom dowel. If you require a tab-tensioned surface, the Series V Access V is the equivalent tensioned model.

What are the optical properties of the Matt White XT1000E surface?

Matt White XT1000E is a unity-gain (1.0) surface with a panoramic 180° viewing cone and typical contrast. It diffuses light evenly for accurate color, and adequate control of ambient light in the audience area is recommended for best results.

Does this screen run on standard building power?

This configuration ships with a 220V quiet motor. Confirm the available circuit at the install location; Draper also offers the Access E in a 110V configuration if your site requires it.

What projectors and mounts are compatible with the Access E?

It works with any commercial front projector matched to its 133" HDTV format and your room's throw distance. Browse our commercial projectors and projector mounts and lifts, or contact us for a throw-distance calculation.

Can the case be installed before the screen during construction?

Yes. Quick-connect wiring lets the case be mounted and wired early, with the screen added later. This supports phased AV installations and coordination with other trades on site.

Does the screen integrate with Crestron or Control4 systems?

Yes. The motor ships with a 3-position switch as standard, and low-voltage or video-interface controls can be specified so the screen can be driven by third-party control systems such as Crestron or Control4.

What warranty and support are included?

The Access E carries Draper's standard 5-year manufacturer warranty, supplied through Creation Networks as an authorized dealer. Contact us at creationnetworks.net for pre-sale specification help and post-sale support.
